PN# 500-13200
Rev. A.1, 10/99
SECURITRON MODEL LCP SERIES ELECTRIC LOCK CONTROL PANEL
TABLE OF CONTENTS AND GUIDE TO THIS MANUAL
The LCP series is a powerful and versatile system with many standard and optional features.
You will generally use only some of these features so this table of contents includes a
description of the type of application that applies to each different section. By studying it first,
you can save considerable time by skipping over those parts of the manual that don't apply.
SECTION 1. DESCRIPTION --------------------------------------------------------------------Page 1
SECTION 1.1 GENERAL ------------------------------------------------------------------------Page 1
This section explains part numbering and allows you to determine your panel configuration.
SECTION 1.2 PANEL POWER -----------------------------------------------------------------Page 1
SECTION 1.3 LOCK CONTROL ---------------------------------------------------------------Page 2
SECTION 1.4 MONITORING--------------------------------------------------------------------Page 2
SECTION 1.5 AUDIBLE ALARM AND ALARM RESET---------------------------------Page 3
The above 4 vital sections contain information that applies to any LCP series panel.
SECTION 2. OPTIONS ---------------------------------------------------------------------------Page 4
Once you have determined the options present or desired on your panel, read the
corresponding section below to learn the function and operation of the supplied option.
SECTION 3. BOARD TERMINAL DESCRIPTIONS --------------------------------------Page 6
This is a reference section. It starts with a drawing showing all terminals on the panel board
and then describes the meaning and function of each. Reading the section explains the
capabilities of the panel, but it's not necessary to complete an installation. As a reference,
the section is of great help in answering questions which arise or planning unusual uses.
SECTION 4. WIRING------------------------------------------------------------------------------Page 7
SECTION 4.1 POWER INPUT WIRING ------------------------------------------------------Page 7
The above section should be read for all installations.
SECTION 4.2 FAIL SAFE LOCKS ------------------------------------------------------------Page 9
If the locks you will be using are fail safe (secure when powered), this section should be
carefully read to determine the proper hookup. Figure 3 (Page 10) shows the several
different ways that fail safe locks may be connected to the panel.
© Copyright, 1999, all rights reserved • Securitron Magnalock Corp., 550 Vista Blvd., Sparks NV 89434, USA
Tel: (775) 355-5625 • (800) MAGLOCK • Fax: (775) 355-5636 • Website: www.securitron.com
An ASSA ABLOY Group company
