Electronic Quick Check - ELNA 6005 heirloom edition Service Manual

Hide thumbs
  • Contents

Advertisement

PDFMAILER.DE
Step
1.
Step LCD, LED
test.
2. Step Keys
3. Step
Buttonhole.
4. Step Bobbin
winder switch.
5. Step Tension
switch.
6. Step Upper
shaft sensor.
7. Step Stepping
motor for
zigzag.
8. Step Stepping
motor for feed.
DIAGNOSIS CHART
Test operation
Turn on the power
switch while
pressing
"REVERSE", AUO-
LOCK", THEN
PRESS "1" within 2
seconds.
Press the keys shown
below in order.
"Reverse, Auto-Lock,
U/D, Twin Needle,
Width -, Width +,
Length -, Length +,
Clear, Enter, Turn-
Over, Memory, Mode,
and stitch patterns 1
to 0.
1. Pull down the
buttonhole lever.
2. Move the
buttonhole lever
back and forth.
1
Shift the bobbin
winder spindle to
the right.
2
Shift the bobbin
winder spindle to
the left.
1
Turn the thread
tension dial.
1
Turn the balance
wheel toward you
to move the needle
bar from the
highest to the
lowest position,
then from the
lowest to the
highest position.
1
Turn the balance
wheel toward you
to move the needle
bar from the
highest to the
lowest position.
Then press
"Reverse" key.
1
Turn the balance
wheel toward you
to move the needle
bar from the
highest to the
lowest position.
Then press
Correct condition
1.
LCD shows (Special
Mode).
2.
LCD shows (Self-Check
Start).
3.
Buzzer sounds.
4.
The 6 LED blinks.
Press Enter to the next test.
1. Buzzer sounds.
2. LCD shows (Key).
3. Each time you press the
key, buzzer sounds.
4. It goes to the Step (3)
automatically if in correct
condition.
1
Buzzer sounds and LCD
shows (BH Sensor L).
2
LCD shows (BH Sensor
H) when the sensor is
closed.
3
LCD shows (BH Sensor
L). when the sensor is
open.
1. Buzzer sounds each time
and LCD shows (Spool).
1
Buzzer sounds and LCD
shows (Thread Tension).
2
LED turns on when the
dial is state "Auto".
3
LED turns off when dial is
turned from "Auto".
1
Buzzer sounds and LCD
shows (PH Sensor L,H).
2
LCD shows (PH Sensor
L,H), when the needle bar
is moved from the lowest
to the highest.
3
LCD shows (PH Sensor
H,L), when the needle bar
is moved from the highest
to the lowest.
1
Buzzer sounds and LCD
shows Zigzag motor.
2
The stepping motor
moves to the primary
setting position.
1
Buzzer sounds and LCD
shows (Feed motor).
2
The stepping motor
moves to the primary
setting position. (feed at
"O").
Defect condition
If the machine does not go to
Test mode, replace the
following parts in order and
recheck
1. Printed circuit board F
2. Printed circuit board K
3. Printed circuit board A
4. Printed circuit board L
If buzzer does not sound when
you press the key, replace the
following parts in order and
recheck.
1. Printed circuit board F.
2. Printed circuit board K.
3. Printed circuit board A.
If machine does not work
properly, replace the following
parts in order and recheck.
1. Buttonhole sensor.
2. Printed circuit board K.
3. Printed circuit board A.
If not working, replace the
following parts in order and
recheck.
1. Printed circuit board K.
2. Printed circuit board A.
If not working, replace the
following parts in order and
recheck.
1. Printed circuit board K.
2. Printed circuit board A.
3. Printed circuit board L.
If not working properly, replace
the following parts in order
and recheck.
1. Upper shaft sensor.
2. Printed circuit board A.
If not working, replace the
following parts in order and
recheck.
1. Stepping motor for zigzag.
2. Printed circuit board A.
If not working properly, replace
the following parts in order
and recheck.
1. Stepping motor for feed.
2. Printed circuit board A.
6
