Base plate
To remove
1.
Remove the screw A and 4 screws B
2.
Remove the base plate C.
To attach
1.
Reverse this procedure
Bed cover
To remove
1.
Remove the 2 screws D
2.
Remove the bed cover E
To attach
Move the drop lever F to the left and attach the bed cover with the screws D.
BASE PLATE AND BED COVER
10
