Atmel AVR AT90S8515-4 Specification Sheet page 12

40P6
40-lead, Plastic Dual Inline
Parkage (PDIP), 0.600" wide
Demension in Millimeters and (Inches)*
JEDEC STANDARD MS-011 AC
SEATING
PLANE
REV. A 04/11/2001
AT90S8515
12
48.26(1.900) REF
4.83(0.190)MAX
3.56(0.140)
3.05(0.120)
2.54(0.100)BSC
0.38(0.015)
0.20(0.008)
*Controlling dimension: Inches
52.71(2.075)
51.94(2.045)
1.65(0.065)
1.27(0.050)
15.88(0.625)
15.24(0.600)
0º ~ 15º
17.78(0.700)MAX
PIN
1
13.97(0.550)
13.46(0.530)
0.38(0.015)MIN
0.56(0.022)
0.38(0.015)
REF
0841GS–09/01
