geometry
A
D
E
G
F
fit
sMall
5'3" (160 CM) - 5'8" (173 CM)
MeDiuM
5'8" (173 CM) - 6'0" (183 CM)
large
6'0" (183 CM) - 6'4" (193 CM)
10.
B
I
C
H
J
K
100 mm fork
sm
mD
lG
a
18.0
19.0
21.0
B
22.4
23.4
24.4
c
69.0
69.0
69.0
D
73.0
73.0
73.0
e
16.9
16.9
16.9
F
42.5
43.5
44.6
g
12.8
12.8
12.8
h
27.4
27.4
27.7
i
4.0
4.5
5.3
J
18.5
18.5
18.5
K
1.5
1.5
1.5
120 mm fork
sm
mD
lG
a
18.0
19.0
21.0
B
22.6
23.6
24.6
c
68.0
68.0
68.0
D
72.0
72.0
72.0
e
16.9
16.9
16.9
F
42.8
43.8
44.9
g
13.0
13.0
13.0
h
27.8
27.8
28.1
i
4.0
4.5
5.3
J
19.3
19.3
19.3
K
1.5
1.5
1.5
*all measurements are in inches
11.
