Diagnostics
Field Description
Dolby Volume Indicates if Dolby Volume is turned on or off
Audio / Video The Audio and Video Mute Status indicates if the audio and/or video have been muted
Mute by the software. The audio mute is either On or Off. The Video Mute describes the
MPEG muting method selected by the software and indicates if the output video is in
the mute state by displaying On or Off, followed by the mute method. Methods
include:
OSD Display
UNMUTED
MUTE to STILL
MUTE to BLACK
Captions The captions mode displays captions present on the service.
Note: The caption options are set via the User Setting Menu, where the subscriber
can enable closed captions and select options.
1 st Caption Row: Caption Detected:
OSD Display
708
608
608 and 708
None
nd
2 Caption Row: Caption Options Set, followed by Service Selected:
OSD Display
708 Set
708 Default
608 Set
608 Default
None Set
OSD Display
CC 1
CC 2
CC 3
CC 4
High-Definition DVR DCX3510-M
365-095-17066-x.1
Description
Displayed if the mute method is not selected.
Displayed if the mute method includes stopping video and
presenting a still frame, similar to a pause function.
Displayed if mute method presents a black screen.
Description
EIA-708 captions detected.
EIA-608 captions detected.
Both EIA-608 and EIA-708 captions detected.
No captions detected.
Description
EIA-708 captions enabled, with options set by user.
EIA-708 captions enabled, with no options set by user.
EIA-608 captions enabled, with options set by user.
EIA-608 captions enabled, with no options set by user.
Captions detected but not enabled.
Definition
Closed Caption service CC 1 (default)
Closed Caption service CC 2
Closed Caption service CC 3
Closed Caption service CC 4
