ELEVATOR - RUDDER PUSHROD INSTALLATION.
Rudder control horn.
Elevator control horn.
Elevator and rudder pushrods assembly follow pictures below.
M2 clevis.
M2 Lock nut.
Attach to servo arm in fuselage.
Attach to elevator - rudder control horn.
Elevator 2.
Elevator 1.
Rudder.
Elevator 2.
Elevator 1.
Rudder.
Throttle.
16 mm.
Servo arm.
15
