■ BG-2527
■ BG-3532
For technical assistance or the sHarK dealer nearest you,
operating instruction
■ BG-2820
■ BG-3735
visit our website at www.shark-pw.com
Model: BG
and parts manual
■ BG-3030
■ BG-3040
97-707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-2527 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shark BG-2527

  • Page 1 Model: BG operating instruction and parts manual ■ BG-2527 ■ BG-2820 ■ BG-3030 ■ BG-3532 ■ BG-3735 ■ BG-3040 For technical assistance or the sHarK dealer nearest you, visit our website at www.shark-pw.com 97-707...
  • Page 2: Table Of Contents

    CoNTeNTS introduction & important safety information .........3-4 component identification ................. 5 assembly instructions ................6 operating instructions................7-8 detergents & cleaning techniques ............9 shut down and clean-up ..............10 storage ....................10 troubleshooting ................11-1 preventative maintenance ..............13 oil change record ................13 models 57, 80 exploded View ............
  • Page 3: Introduction & Important Safety Information

    INTRodUCTIoN & IMpoRTaNT SafeTy INfoRMaTIoN thank you for purchasing this pressure Washer. WARNING: Risk of asphyxiation. WaRNING Use this product only in a well We reserve the right to make changes at any time ventilated area. without incurring any obligation. 5.
  • Page 4: Important Safety Information

    IMpoRTaNT SafeTy INfoRMaTIoN 14. Be certain all quick coupler fittings are secured WARNING: Flammable liquids WaRNING can create fumes which can ig- before using pressure washer. nite, causing property damage WARNING: Protect machine from WaRNING or severe injury. freezing. WARNING: Risk of explosion 15.
  • Page 5: Component Identification

    CoMpoNeNT IdeNTIfICaTIoN Unloader pump detergent Injector Single lance Wand Spray Gun Inlet Trigger Screen Garden hose (not included) pressure Nozzle Starter Grip high pressure hose detergent Bucket (not included) pump — develops high pressure. Wand — must be connected to the spray gun. Starter Grip—...
  • Page 6: Assembly Instructions

    aSSeMBly INSTRUCTIoNS Carriage Bolts hose/Spray Gun handle Bolt Storage Bracket alignment holes Washer frame assy. Studs STep 1: attach the handle to the STep 2: insert the carriage bolt STep 3: attach the spray gun/hose frame of the pressure washer. Note: through the holes from the outside storage handle, and bracket to it may be necessary to move the...
  • Page 7: Operating Instructions

    opeRaTING INSTRUCTIoNS pump oil dipstick engine oil dipstick oil Window STep 1: check engine oil level. oil level should be level with the bottom STep 2: remove shipping cap and of the oil filler neck. Be sure the machine is level when checking the oil install oil dipstick.
  • Page 8 opeRaTING INSTRUCTIoNS (CoNT.) on-off Switch STep 8: turn the engine switch to "on" position. STep 9: pull the starter grip. if the engine fails to start after  pulls, squeeze the trigger gun to release pressure on Briggs engines, move the throttle lever to "Fast" and repeat step.
  • Page 9: Detergents & Cleaning Techniques

    deTeRGeNTS & GeNeRal CleaNING TeChNIqUeS TheRMal pUMp pRoTeCTIoN WARNING: Some detergents WaRNING may be harmful if inhaled or ingested, causing severe nau- if you run the engine on your pressure washer for 3-5 minutes without pressing the trigger on the spray gun, sea, fainting or poisoning.
  • Page 10: Shut Down And Clean-Up

    ShUTTING doWN aNd CleaN-Up on-off Switch STep 1: remove detergent suc- STep 2: turn off the engine. STep 3: turn off wa- tion tube from container and insert ter supply. into one gallon of fresh water. slide nozzle forward for low pressure or to connect black detergent nozzle.
  • Page 11: Troubleshooting

    TRoUBleShooTING pRoBleM poSSIBle CaUSe SolUTIoN loW opeRaTING insufficient water supply. closed use larger garden hose; clean inlet water pReSSURe faucet screen. open faucet. old, worn or incorrect spray match nozzle number to machine and/or nozzle replace with new nozzle. plumbing or hose leak check plumbing system for leaks.
  • Page 12 TRoUBleShooTING pRoBleM poSSIBle CaUSe SolUTIoN oIl SqUIRTS oUT pump over filled with oil maintain oil level at red dot on sight glass at of oIl Cap oN rear of pump or at top of notch on dipstick. pUMp eNGINe opeRaTeS not enough gas or engine oil Fill tank with gas.
  • Page 13: Preventative Maintenance

    pReveNTaTIve MaINTeNaNCe this pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. contact your dealer for maintenance.
  • Page 14: Models 57, 80 Exploded View

    exploded vIeW - 2527, 2820 Models 97-707 • Bg • rev. 5/07...
  • Page 15: Models 57, 80 Exploded View Parts List

    exploded vIeW paRTS lIST - 2527, 2820 ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN -0103 grommet, rubber, nozzle 90-19710 Bolt, 1/4" x 3/4" Flange Holder 90-1001 Bolt 3/8" x -1/4" 95-0710491 Handle, grab, red -30081 pump protector 1/4" 11-0358 label, Bg models pump, see specifications pages 95-07104945...
  • Page 16: Models 3030, 353, 3735 Exploded View

    exploded vIeW - 3030, 3040, 3532, 3735 74 75 BG-304037 60 59 23 22 97-707 • Bg • rev. 5/07...
  • Page 17: Models 3030, 353, 3735 Exploded View Parts List

    exploded vIeW paRTS lIST - 3030, 3040, 3532, 3735 ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN -0103 grommet, rubber, nozzle 4-0100000 Hose, 1/4", push-on, Holder Fuel line 1 ft. 95-0710491 Handle, grab, red -1089 Hose Barb, 1/4" Barb x 1/4" ml pipe, 90°...
  • Page 18 exploded vIeW paRTS lIST - 3030, 3040, 3532, 3735 ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 4-1803000 nozzle, saQcmeg 0003, 5-3080 unloader, al-Vrt 607 red (304037) w/easy start (3040) 4-18-3015 nozzle, saQcmeg 1503 95-0710116B Block, inloader, Yellow (304037) 3/8" x 3/8" Brass (3040) 4-180305 nozzle, saQcmeg 503 90-100...
  • Page 19: Hose And Spray Gun Assembly

    hoSe & SpRay GUN aSSeMBly hoSe & SpRay GUN aSSeMBly paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 4-01103 Wand assy., side grip W/1/4” -00 coupler, 3/8” Female, Brass coupler 35-1/” (Bg) 3-101 injector, detergent, non-adjust, 4-0146 spray gun, ap 1000 (Bg) 3-5 gpm, .083 -000 coupler, 1/4”...
  • Page 20: Specifications

    SpeCIfICaTIoNS pressure Nozzle pump Unloader engine engine pump pump pulley Model (pSI) Size pump part No. part No. part # pulley part No. Bg-8037 000 sd3030 5-1409 5-339 gX160 (5.5) 5-0104 aK74H 5-40107401 Bg-5737 700 sd3030 5-1409 5-339 gX00 (6.5) 5-01041 BK80H 5-40408001...
  • Page 21 SpeCIfICaTIoNS pump Bushing engine pulley engine Bushing Belt Belt Model Bushing part No. pulley part No. Bushing part No. Size part No. Bg-8037 4mm 5-5104 aK39H 5-40103901 Hx3/4" 5-511075 aX33) 5-60033 Bg-5737 4mm 5-5104 BK36H 5-40403601 Hx3/4" 5-511075 BX3 5-60403 Bg-303037 4mm 5-5104...
  • Page 22 d SeRIeS pUMp exploded vIeW 5-1409 ToRqUe SpeCS item # Ft.-lbs d SeRIeS pUMp exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 70-160117 Brass plug 3/8 70-009 crankcase 70-18011 screw see Kits Below plunger oil seal 70-00318 Bearing cover 70-060181...
  • Page 23 d SeRIeS pUMp exploded vIeW paRTS lIST (CoNT.) ITeM paRT No. deSCRIpTIoN 70-18013 connecting rod screw 70-070005 sight glass 70-06030 gasket 70-0035 crankcase cover 70-060104 o-ring Ø.6 x 107.6 * available in kit (see below) repair Kit 70-61 408 70-61 409 70-61 404 70-6 008 70-6086...
  • Page 24 SM-1 SeRIeS pUMp exploded vIeW 5-1412 SM3540 5-1420 SM4035-1 ToRqUe SpeCS item # Ft.-lbs SM-1 SeRIeS pUMp exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 70-0031 crankcase 70-16010 Brass plug 1/" 70-06001 plunger guide 70-060307 copper Washer 1/" see Kits Below plunger oil seal 70-16016...
  • Page 25 SM-1 SeRIeS pUMp exploded vIeW paRTS lIST (CoNT.) ITeM paRT No. deSCRIpTIoN 70-180001 plunger Bolt 70-14001 copper spacer 70-060103 o-ring Ø1.78 x 7.66 70-000904 teflon ring see Kits Below plunger (4035, 4035H) see Kits Below plunger (4030, 5030) see Kits Below plunger (3540) 70-140015 copper spacer...
  • Page 26 aR-al UNloadeR exploded vIeW aNd paRTS lIST aR - al 607 #9.802-367.0 7-8 Gpm, 4200 psi 97-707 • Bg • rev. 5/07...
  • Page 27 aR-al UNloadeR exploded vIeW aNd paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN 83-005150010 check connector 83-005106301 spring pin 83-005060108 ‡ o-ring 068 83-005000101 Back ring 83-00510000 shutter spring 83-005060101 ‡ o-ring 050 83-00410000 shutter 83-00500003 Body By pass 1/4 g-F 83-004060109 ‡...
  • Page 28 vBa35 UNloadeR exploded vIeW 5-3329 5-3330 vBa35 UNloadeR exploded vIeW paRTS lIST ITeM paRT No. deSCRIpTIoN ITeM paRT No. deSCRIpTIoN poppet kIT B 70-0045 Body Valve (m/s) 70-11007 70-00444 Body Valve (g/e/d) 70-14080 seal Washer, 3/8" 70-060141 o-ring kit a, C 70-180004 Hollow Bolt, 3/8"...
  • Page 29 PARTICULAR PURPOSE. SHARK does not authorize any other party, including authorized Dealers, to make any representa- tion or promise on behalf of SHARK, or to modify the terms, conditions, or limitations in any way. It is the buyer’s responsibility to ensure that the installation and use of SHARK products conforms to local codes. While SHARK attempts to assure that its products meet national codes, it cannot be responsible for how the customer chooses to use or install the product.
  • Page 30 Form #97-707 / 8.914-443.0 • revised 5/07 • printed in u.s.a.
