Shark
Read instructions carefully before attempting to assemble, install, operate or service this pressure
washer. Failure to comply with instructions could result in personal injury and/or property damage!
G Pump Volume At Pump Head: 3.5 GPM/210 GPH
G Pump Pressure At Pump Head: 2500 PSI
G Machine Power: 9.0 HP Gasoline Engine, Manual Start
G Machine Weight: 145 Lbs.
G Shipping Weight: 185 Lbs.
G Machine Dimensions: Length = 34", Width = 24.5", Height = 23.5"
Output specifications are based on engine power curves at 100 meters
above sea level and 25
SAE J1349.
SERIAL NUMBER:
DATE PURCHASED:
FOR SALES AND SERVICE, PLEASE CONTACT:
MODEL B2535H/1
R
SPECIFICATIONS
o
C ambient temperature in accordance with
SHARK PRESSURE WASHERS
21 INVERNESS WAY EAST
ENGLEWOOD, CO 80112
1-800-771-1881
OPERATING INSTRUCTIONS
AND PARTS MANUAL
Advertisement
Table of Contents
Related Manuals for Shark B2535H/1
Summary of Contents for Shark B2535H/1
-
Page 1: Specifications
MODEL B2535H/1 Shark OPERATING INSTRUCTIONS AND PARTS MANUAL Read instructions carefully before attempting to assemble, install, operate or service this pressure washer. Failure to comply with instructions could result in personal injury and/or property damage! SPECIFICATIONS G Pump Volume At Pump Head: 3.5 GPM/210 GPH G Pump Pressure At Pump Head: 2500 PSI G Machine Power: 9.0 HP Gasoline Engine, Manual Start... - Page 2 Fuel spillage or vapors could ignite if be replaced. Contact your dealer for engine is hot. replacement decals. Do not place hands or feet on non- insulated areas of the pressure washer when starting gasoline engine. Page 2 Shark B2535H/1...
- Page 3 WAND PRESSURE NOZZLE TRIGGER GUN PRESSURE ENGINE NOZZLE HOLDERS PRESSURE HOSE RELIEF VALVE 24.5” PUMP THERMAL RELIEF VALVE 34” UNLOADER VALVE PRESSURE HOSE CONNECTOR 23.5” GARDEN HOSE CONNECTOR Figure 1 - Machine Component Layout Shark B2535H/1 Page 3...
-
Page 4: Installation
Moisture reaching the equipment will reduce the pressure washer’s service life. Figure 2 - Pressure Hose Installation All installations should comply with the local codes covering such installations. Page 4 Shark B2535H/1... -
Page 5: Gasoline Engine
Move throttle lever tom of filler neck only. Use lead free gasoline mini- to half throttle position. mum 86 octane. DO NOT use gasoline containing more than 5% methanol, 10% ethanol, or 15% MTBE. Shark B2535H/1 Page 5... -
Page 6: Maintenance
1. Protect from freezing by storing in a heated area, or by flushing the system with antifreeze (use an auto- motive engine antifreeze or windshield washer Page 6 Shark B2535H/1... -
Page 7: Pressure Relief Valve
Tampering with the factory set- Refer to the provided gasoline engine manual for rec- ting may cause personal injury and/or proper ty ommended maintenance. damage, and will void the manufacturer warranty. For replacement refer to Figure 7. Shark B2535H/1 Page 7... -
Page 8: Troubleshooting Guide
IMPORTANT If the pressure washer demonstrates other symptoms or the corrective ac- tions listed do not correct the problem, contact the local authorized Shark Pressure Washer Service Center. The Shark Pressure Washer Service Cen- ter can be identified by contacting:... - Page 9 When ordering from your dealer, please provide the following: Model Number: B2535H/1 Machine Serial Number: ________________________________ Component Part Number: _______________________________ Description: __________________________________________ FOR HELP OR ADDITIONAL INFORMATION, CONTACT: Customer Service Department Shark Pressure Washers 21 Inverness Way East Englewood, CO 80112...
- Page 10 Part No. Description Qty. 375441 Chassis 817322 Hubcap Fig. 9 Trigger Gun/Wand Assembly 848616 Push Nut 5/8" 444469 Decal Shark Detergent Flat Washer 5/8" Fig. 7 Pump Assembly 834154 Decal Winterize 859815 Grommet (Nozzle Holders) 919537 Engine Pulley 890783 Engine Warning Tag...
- Page 11 Relief Valve Seat Replacement Parts 615541 Bolt Unloader Valve ✪ 753025 936633 Flat Washer w/Seal O-Ring Repair Kit ✪ 921509 ✪ 753026 Unloader Valve Discharge Repair Kit ✪ 753027 890769 Unloader Warning Tag Stem Repair Kit Shark B2535H/1 Page 11...
- Page 12 Figure 8 - Pump, Exploded View Page 12 Shark B2535H/1...
- Page 13 Sight Glass 877672 Seal Packing Kit 18 mm 818575 O-Ring for Sight Glass 753039 Complete Valve Assembly Kit ✤ 860141 Crankshaft Snap Ring 753107 Ceramic Sleeve Kit 18 mm ❖ 808895 Ball Bearing 877655 Plunger Seal Kit Shark B2535H/1 Page 13...
- Page 14 Part No. Description Qty. 860447 Trigger Gun Fig. 10 799012 Pressure Nozzle (Yellow) 915786 Quick Disconnect Plug 799024 Pressure Nozzle (White) 826169 Quick Disconnect 799144 Pressure Nozzle (Green 936701 Wand 826177 Quick Disconnect 799000 Pressure Nozzle (Red) Page 14 Shark B2535H/1...
- Page 15 Plunger Guide Seat O-Ring 851190 Inlet Fitting ✪ Plunger Guide Backring 860496 Right Gun Shell ✪ Plunger Guide O-Ring ✪ Plunger Guide ✪ Replacement Parts Plunger Rod ✪ ✪ 877471 Plunger Seat Trigger Gun Repair Kit Shark B2535H/1 Page 15...
-
Page 16: Warranty
Shark will at its option repair or replace any part covered by this warranty which is defective under normal use for one year at no charge for parts or labor. All defects must be verified by an authorized Shark Pressure Washers service location.
