BG-2527
BG-3532
For technical assistance or the SHARK dealer nearest you,
visit our website at www.shark-pw.com or call 360-833-1600
MODEL: BG
OPERATING INSTRUCTION
AND PARTS MANUAL
BG-2820
BG-3735
BG-3030
BG-3040
97-707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-2527 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shark BG-2527

  • Page 1 MODEL: BG OPERATING INSTRUCTION AND PARTS MANUAL BG-2527 BG-2820 BG-3030 BG-3532 BG-3735 BG-3040 For technical assistance or the SHARK dealer nearest you, visit our website at www.shark-pw.com or call 360-833-1600 97-707...
  • Page 3: Table Of Contents

    CONTENTS Introduction & Important Safety Information ......... 4-5 Component Identification ................. 6 Assembly Instructions ................7 Operating Instructions ................8-9 Detergents & Cleaning Techniques ............10 Shut Down and Clean-Up ..............11 Storage ....................11 Troubleshooting ................12-13 Preventative Maintenance ..............14 Oil Change Record ................
  • Page 4: Introduction & Important Safety Information

    INTRODUCTION & SAFETY INFORMATION Thank you for purchasing this pressure washer. WARNING: Risk of asphyxiation WARNING — Use this product only in a well All information in this manual is based on the latest ventilated area. product information available at the time of printing. 3.
  • Page 5 SAFETY INFORMATION CONT. 9. Do not operate with spray gun in the off position for WARNING: High pressure spray WARNING extensive periods of time as this may cause dam- can cause paint chips or other age to the pump. particles to become airborne and fly at high speeds.
  • Page 6: Component Identification

    COMPONENT IDENTIFICATION Unloader Pump Detergent Injector Straight Through Wand Spray Gun Inlet Trigger Screen Pressure Nozzle Garden Hose (not included) Starter Grip High Pressure Hose Detergent Bucket (not included) Pump — Develops high pressure. Wand — Must be connected to the spray gun. Starter Grip—...
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Carriage Bolts Hose/Spray Gun Handle Bolt Storage Bracket Alignment Holes Washer Frame Assy. Studs STEP 1: Attach the handle to the STEP 2: Insert the carriage bolt STEP 3: Attach the spray gun/hose frame of the pressure washer. Note: through the holes from the outside storage handle, and bracket to It may be necessary to move the...
  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS Pump Oil Dipstick Engine Oil Dipstick Oil Window STEP 1: Check engine oil level. Oil level should be level with the bottom of STEP 2: Remove shipping cap and the oil filler neck. Be sure the machine is level when checking the oil level. install oil dipstick.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS (CONT.) On-Off Switch STEP 8: Turn the engine switch to "On" position. STEP 9: Pull the starter grip. If the engine fails to start after 2 pulls, squeeze the trigger gun to release pres- On Briggs engines, move the throttle lever to "Fast" sure and repeat step.
  • Page 10: Detergents & Cleaning Techniques

    DETERGENTS & GENERAL CLEANING TECHNIQUES WARNING: Some detergents may THERMAL PUMP PROTECTION WARNING be harmful if inhaled or ingested, causing severe nausea, fainting If you run the engine on your pressure washer for 3-5 or poisoning. The harmful ele- minutes without pressing the trigger on the spray gun, ments may cause property dam- circulating water in the pump can reach high tempera- age or severe injury.
  • Page 11: Shut Down And Clean-Up

    SHUTTING DOWN AND CLEAN-UP On-Off Switch STEP 1: Remove detergent suction STEP 2: Turn off the engine. STEP 3: Turn off wa- tube from container and insert into one ter supply. gallon of fresh water. Slide nozzle for- ward for low pressure or to connect black detergent nozzle.
  • Page 12: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Insufficient water supply. Closed Use larger garden hose; clean inlet water LOW OPERATING faucet screen. Open faucet. PRESSURE Old, worn or incorrect spray Match nozzle number to machine and/or nozzle replace with new nozzle. Plumbing or hose leak Check plumbing system for leaks.
  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION OIL SQUIRTS OUT OF Pump over filled with oil Maintain oil level at red dot on sight glass at rear OIL CAP ON PUMP of pump or at top of notch on dipstick. Not enough gas or engine oil Fill tank with gas.
  • Page 14: Preventative Maintenance

    PREVENTATIVE MAINTENANCE This pressure washer was produced with the best available materials and quality craftsmanship. However, you as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. Contact your dealer for maintenance.
  • Page 15: Models 2527, 2820 Exploded View

    EXPLODED VIEW - 2527, 2820 Models 97-705, 97-707 • REV. 9/05...
  • Page 16: Models 2527, 2820 Exploded View Parts List

    EXPLODED VIEW PARTS LIST - 2527, 2820 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2-0103 Grommet, Rubber, Nozzle 90-4001 Washer, 5/16" Flat Holder 90-2001 Nut, 5/16" ESNA 95-07104921 Handle, Grab, Red 90-4000 Washer, 1/4" 11-0359 Label, BX Models 90-19710 Bolt, 1/4"...
  • Page 17 EXPLODED VIEW PARTS LIST - 2527, 2820 ITEM PART NO. DESCRIPTION 90-1007 Bolt, 5/16" x 1" NC 2-01403 Bushing, 5/8" Snap 90-4000 Washer, 1/4" Flat, SAE 90-2000 Nut, 1/4" ESNA, NC 90-1030 Bolt, 8mm x 30mm Hex (252731, 282039) (282037) 90-1031 Bolt, 8mm x 20mm, HH (282037)
  • Page 18: Models 3030, 3532, 3735 Exploded View

    EXPLODED VIEW - 3030, 3040, 3532, 3735 74 75 BG-304037 60 59 23 22 97-705, 97-707 • REV. 9/05...
  • Page 19: Models 3030, 3532, 3735 Exploded View Parts List

    EXPLODED VIEW PARTS LIST - 3030, 3040, 3532, 3735 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2-0103 Grommet, Rubber, Nozzle 4-011184 Injector, Detergent Assy, Non-` Holder Adj, 3-5 GPM, 0.083 95-07104921 Handle, Grab, Red 4-02100000 Hose, 1/4", Push-On, Fuel Line 1 ft.
  • Page 20 EXPLODED VIEW PARTS LIST - 3030, 3040, 3532, 3735 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4-12804000 Nozzle, SAQCMEG, 0004.5, 2-1024 Elbow, 1/2" Street, Brass Red (353237, 373537, (304037) 373539) 2-0053 Elbow, 1/2 JIC, 3/8, 90° 4-12804015 Nozzle, SAQCMEG 1504.0, (304037) Yellow (353237, 373537, 4-02047920...
  • Page 21: Hose And Spray Gun Assembly

    HOSE & SPRAY GUN ASSEMBLY HOSE & SPRAY GUN ASSEMBLY PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4-0110321 Wand Assy., 35-1/2” Side Grip, 4-020750C Hose, 3/8" x 50', 2 Wire w/Couplers, (BX) Pressure Flex w/Coupler 4-0110322 Wand Assy., Side Grip W/1/4” (BX-373539) Coupler 35-1/2”...
  • Page 22: Specifications

    SPECIFICATIONS Pressure Nozzle Pump Unloader Engine Engine Pump Pump Pulley M o d e l G P M (PSI) S i z e P u m p Part No. Part No. Part # Pulley Part No. BX-282039 2000 HC340R 5-1800 5-3309 5-0104 BK80H...
  • Page 23: Specifications

    SPECIFICATIONS Pump Bushing Engine Pulley Engine Bushing Belt Belt M o d e l B u s h i n g Part No. Pulley Part No. B u s h i n g Part No. S i z e Part No. BX-282039 24MM 5-512024...
  • Page 25 FITNESS FOR A PARTICULAR PURPOSE. SHARK does not authorize any other party, including authorized Dealers, to make any representation or promise on behalf of SHARK, or to modify the terms, conditions, or limitations in any way. It is the buyer’s responsibility to ensure that the installation and use of SHARK products conforms to local codes. While SHARK attempts to assure that its products meet national codes, it cannot be responsible for how the customer chooses to use or install the product.
  • Page 26 Form #97-707 • Revised 9/05 • Printed in U.S.A.

This manual is also suitable for:

Bg-3532Bg-2820Bg-3735Bg-3040Bg-3030
