Flight Battery Installation,

Linking and ESC Arming
WARNINGS
Always turn the transmitter's power switch ON before
plugging the battery into the plane.
The motor will not operate unless the throttle stick is
first moved to the lowest position.
Keep clear of propeller to prevent bodily harm.
NOTE: The Micro Calypso is equipped with an auto-linking
feature. This means the transmitter will automatically link
to the plane after they are turned on.
Right
Stick
Right
Stick
6. Move the elevator/rudder stick (right stick) and confirm
the elevator and rudder respond correctly.
Throttle
Left
Stick
CAUTION: Do not run the Micro Calypso motor for more
than 15 seconds when not in flight. Running the motor for
extended times while the plane is not flying could cause
damage to the motor.
1. Move the throttle stick all the
way down.
2. Switch the power ON.
3. The red LED lights up and a
"beep" will be heard.
4. Connect the battery to the
ESC plug in the bottom of the
plane. Observe the correct
polarity.
5. Secure the battery on the
bottom of the Micro Calypso
fuse using the hook and loop
material.
Elevator
Rudder
7. Move the throttle stick (left
stick) up gently to confirm the
motor/prop spin.

LED Display

(Located Behind Flight Battery)
When this means
is
the
Tx & Rx are
Steady
on
linked & ready.
Rx
The throttle's in
LED
Slow the Hi position
inside
Flash (The motor will
the
not activate).
plane
Fast The battery
Flash is low.
Tx Fast The battery
LED Flash is low.
RTF SERVO REVERSING
The rudder and elevator servo direction can be reversed by
simply switching the location of the reversing switches.
REVERSED
NORMAL

DUAL RATES

The Micro Calypso transmitter (RTF only) is equipped with
a dual rate switch which allows you to adjust the amount
of throw the elevator and rudder have. With the dual rate
switch down, you can fly on high rates (more elevator/rudder
throw for experienced pilots) or you can move the dual rate
switch up and fly on low rates (less elevator/rudder throw
for inexperienced pilots) to make the plane easier to fly.
You can also adjust the elevator and rudder throw by
changing the position of the linkage at the mounting point
on the elevator and rudder. Moving the elevator linkage to
the upper hole will increase throw and elevator response.
Moving the rudder linkage to the inner hole will increase
rudder throw and rudder response.
1 2 3 4
RUDDER / ELEVATOR CONTROL
SURFACE CENTERING
Before your first flight or after a crash you will need to check
the centering of the rudder and elevator control surfaces.
To prevent excessive transmitter trim you should first make
mechanical adjustments to the rudder and elevator servo
linkages. The linkages have a "U" shaped section in them
that can be compressed or expanded to adjust the control
6
You
the should
Move the throttle stick to
the lowest position, until the
LED is steady ON. Then
the motor will activate.
Charge the
battery.
Replace the
Tx batteries.
1 2 3 4 5 6
RUDDER ELEVATOR
Low Rates
High Rates
5 6
