Team C T8TEt8te Assembly Instructions Manual page 8

9
Front Hub Carrie
Bag
前轮座
T08675 M4x10 Screw
M4x10 螺丝
...............2
T08751 Front Hub Carrier Bushing
前輪座軸套
.........4
T08751 M4x16 Screw
M4x16 螺丝
......4
10
Front Suspension
Bag
前悬吊系统
T08645 4x73
T08674 M3x35
Assemble both Left and Right
L
R
组装左和右
D
-
T08675 M4x10
TG8001
Front Lower Arm
前下摆臂
L
R
D
-
T08673 M3x16
T08764
Front Arm Mount-F
前摆臂固定座-前
T08751
Front Hub Carrier Bushing
前輪座軸套
T08764
T08674 M3x15
Front Arm Mount-R
前摆臂固定座-后
T08645 4x73
5
T08751 M4x16
T08751 M4x16
T08645 4x73 Arm Pin
4x73 擺臂軸
......2
T08674 M3x35 Screw
M3x35 螺丝
............2
T08674 M3x15 Screw
M3x15 螺丝
.........2
T08673 M3x16 Screw
M3x16 螺丝
......2
T08673 M3x16
