Team C T8TEt8te Assembly Instructions Manual page 7

D
-
7
Front Swaybar
Bag
前防倾杆
T08756 M3x3
T08601
Swaybar Mount
防倾杆固定座
T08674 M2.5x8
T08674
T08601 M3x3
M2.5x8
-
8
Front Hub Carrie
Bag
前轮座
TG8018
133mm Drive Shaft
133mm传动轴
TG8018 5x8.5
TG8018 2.5x12.8 Pin
2.5x12.8钢针
..................2
T08665 13x19x4 Ball Bearing
13x19x4 轴承
.........2
T08664 8x16x5 Ball Bearing
8x16x5 轴承
.........2
Assemble both Left and Right
L
R
组装左和右
T08647
Front Swaybar
前防倾杆
D
TG8018 2.5x12.8
T08772
CVD Connecting Cup
CVD接杯
TG8018 5x8.5 CVD Shaft
5x8.5 CVD轴
........................2
T08603 King Pin Bushing
大王銷軸套
...............4
TG8015 2.5x16.8 Pin
2.5x16.8 钢针
...............2
T08639 M4x4 Screw
M4x4 螺丝
.....................2
T08673 M4x14 Screw
M4x14 螺丝
......4
Assemble as many times as specified
x2
需组装数量
Left
Right
Front Hub Carriers 12 Degree
T08603
前轮座12度
T08665 13x19x4
T08673 M4x14
L
R
4
T08674 M2.5x8 Screw
M2.5x8螺丝
..................3
T08601/T08756 M3x3 Screw
........................4
T08756 6.8 Ball stud
6.8球头
.....................2
T08755 6.8 Ball stud
6.8球头
...........................2
T08760 6.8 Ball End
6.8球头座
..................2
T08760
T08756
T08755
x2
T08604
Steering Block-Left Steering Block-Right
转向臂-左 转向臂-右
T08603
King Pin Bushing
大王銷軸套
T08664 8x16x5
T08639 M4x4
TG8015 2.5x16.8
M3x3螺丝
TG8015
Wheel Hex Hub
六角轮座
