Team C T8TEt8te Assembly Instructions Manual page 14

E
-
21 Rear Swaybar
Bag
后防倾杆
T08601/T08756 M3x3 Screw
M3x3螺丝
........................4
T08601 M2.5x8 Screw
M2.5x8螺丝
..................3
T08756 6.8 Ball stud-Swaybar
6.8球头-防倾杆
.....................2
T08755 6.8 Ball stud-Swaybar
6.8球头-防倾杆
...........................2
T08601 M2.5x8
T08601 M3x3
22
Rear Hub Carrie
-
Bag
后轮座
T08605 T08605
Rear Hub Carriers-L Rear Hub Carriers-R
后轮座-左 后轮座-右
TG8015 2.5x16.8
Screw
Cement
84001 M4x4
Apply threadlocker(screw cement)
打螺丝胶水
Screw
Cement
T08756 M3x3
Screw
Cement
T08601
Swaybar Mount
防倾杆固定座
E
T08664 8x16x5
TG8015
Wheel Hex Hub
六角轮座
Assemble both Left and Right
L
R
组装左和右
x2
T08756
T08760
T08755
T08601 M2.5x8
T08601 M3x3
TG8018
133mm Drive Shaft
133mm传动轴
T08772
CVD Connecting Cup
CVD接杯
T08665 13x19x4
Assemble as many times as specified
x2
11
需组装数量
T08756 M3x3
Screw
Cement
T08647
Rear Swaybar
后防倾杆
TG8018 2.5x12.8 Pin
TG8018 5x8.5 CVD Shaft
T08665 13x19x4 Ball Bearing
TG8018 2.5x12.8
T08664 8x16x5 Ball Bearing
TG8015
84001 M4x4 Screw
M4x4螺丝
L
R
2.5x12.8钢针
..................2
5x8.5 CVD轴
........................2
13x19x4 轴承
.........2
8x16x5 轴承
.........2
2.5x16.8 Pin
2.5x16.8钢针
..................2
........................2
