Team C T8TEt8te Assembly Instructions Manual page 10

13
Steering Turnbuckle
Bag
转向拉杆
Steering-Left
1:1 x1
转向-左
Steering-Right
1:1 x1
转向-右
TG8020 4x86 Turnbuckle
4x86 拉杆
14
Front Upper/Steering Turnbuckle
前上/转向拉杆
Front Upper Turnbuckle-Right
前上拉杆-右
T08674 M3x16 Screw T08666 M3 Nylon Nut
M3x16 螺丝
......2
Ture-to -scale diagram
1:1
图形比例
D
-
.........2
D
-
Bag
Steering Turnbuckle-Right
转向拉杆-右
T08666 M3
T08666 M3
T08676 M3x25 Screw
M3尼龙螺母
............6
Assemble as many times as specified
x1
需组装数量
Approx.64.5mm
大约64.5mm
▲Projection.Note direction
注意方向
Approx.64.5mm
大约64.5mm
▲Projection.Note direction
注意方向
T08753 6.8 Ball stud
6.8球头
............2
Steering Turnbuckle-Left
转向拉杆-左
Front Upper Turnbuckle-Left
前上拉杆-左
T08676 M3x18 Screw
M3x25 螺丝
......2
7
T08754 6.8 Ball stud T08760 6.8 Ball End-Steering
6.8球头
............2
M3x18 螺丝
......2
6.8 球头座-转向
......4
