Transmitter Preparation - Team C T8TEt8te Assembly Instructions Manual

Transmitter Preparation

调整遥控器
A new Ni-MH battery must be charged before it is used.Refer to the charger instruction manual for charging.
在使用之前，一个新电池必须先充电。详情请参考充电器说明书。
Set up the radio control system as indicated below.
如下图所示安装接收机控制系统。
Battery
电池
2
11
5
DIGITAL
PROPORTIONAL
RADIO CONTROL
SYSTEM
6
ON
8 5
10
OFF
1
Start
Finish
Tools required
组裝需要的工具
Needie Nose Pllers
尖嘴钳
Differential Grease
差速油
Molybdenum Grease(Black)
钼油(黑)
Hex Wrench Hex Wrench
十字套筒
六角扳手
3
8
Transmitter
发送机
6
ON
10
OFF
Install batteries.(Transmitter)
1
Extend the antenna.(Transmitter)
2
Connect the battery
3
Extend the antenna.(Reveiver)
4
Center the trims.
5
Switch on.(Transmitter)
6
Switch on.(Reveiver)
7
Make sure the servos are in command.
8
Switch off.(Reveiver)
9
Switch off.(Transmitter)
10
Retract the antenna(Transmitter)
11
Awl
锥
H154
Body Reamer
车壳绞刀
No need to pre-drill precise holes
(1mm to 15mm)can be drilled
可以对预钻的孔准确的钻1mm-15mm
Servo
伺服机
开始
结束
Screw Cement
Grease
螺丝胶水
润滑油
Wire Cutters
钢丝钳
Sharp Hobby knife
美工刀
Electronic Speed
Controller
电子加速控制器
4
Receiver
接收机
1 安装电池(发送机)
2 拉出天线(发送机)
3 连接电池
4
拉出天线(接收机)
5 中心对整齐
开关(发送机)
6
7
开关(接收机)
8
确定控制伺服机
9 关闭开关(接收机)
10
关闭开关(发送机)
11
收回天线(发送机)
H162
Instant Glue
瞬间胶水
H096
ROUND CUTTER
剪刀
For trimming bodies!
用于修剪車壳！
Motor
马达
7
9
Switch
开关
