4
USING A DMX512 CONTROLLER
4.1

BASIC ADDRESSING

Connect all of the units in series using standard DMX512 signal cable or the IP65 rated cable
provided.
Set the DMX512 address in the DMX menu.
It is possible to have the same DMX address or independent addresses for each fixture.
4.2

CHANNEL ASSIGNMENT

Note: This product have three DMX512 channel configuration:
ARC 1+D
STAGE 1
4 USING A DMX512 CONTROLLER
CHANNEL VALUE
1
0 255
2
0 255
3
0 255
4
0 255
0 10
11 35
36 60
61 85
86 110
111 135
136 160
161 185
186 210
5 211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
251 255
0 10
6
11 255
FUNCTION
DIMMER
RED
Ch2 will control the TIME if Ch7 choose custom01-10
GREEN
Ch3 will control the FADE if Ch7 choose CUSTOM01-10
BLUE
MARCO
No function
RED 100% / GREEN UP / BLUE 0%
RED DOWN / GREEN 100% / BLUE 0%
RED 0% / GREEN 100% / BLUE UP
RED 0% / GREEN DOWN / BLUE 100%
RED UP / GREEN 0% / BLUE 100%
RED 100% / GREEN 0% / BLUE DOWN
RED 100% / GREEN UP / BLUE UP
RED DOWN / GREEN DOWN / BLUE 100%
WHITE 1: 3200K
WHITE 2: 3400K
WHITE 3: 4200K
WHITE 4: 4900K
WHITE 5: 5600K
WHITE 6: 5900K
WHITE 7: 6500K
WHITE 8: 7200K
WHITE 9: 8500K
STROBE
No function
Strobe speed
13
STAGE 1 , ARC 1 and
