PRODUCT (GENERAL) PRODUCT INTRODUCTION This product is designed for indoor use. Suitable applications include wash or effect lighting for architectural, stage or nightclub applications. This product can also be installed for use in signage and advertising using the dynamic functions available with DMX512 control.
TECHNICAL SPECIFICATIONS LED MODULE LED MODULE: Voltage 100~240V...50/60Hz Rated Power 18pcs (6 x RED / 6 x GREEN / 6 x BLUE) LED/Unit Output/LED Environment Temperature -20 ~40 Cooling Forced air convection Dimensions 240 x 210 x160mm Weight 2.5Kg 1 PRODUCT(GENERAL) 2008.8.13...
SAFETY WARNING IMPORTANT ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA. This product must be installed by a qualified professional. Always operate the equipment as described in the user manual.
INSTALLATION MOUNTING HANGING The LED PAR can be mounted in a hanging position using the supporting bracket. The bracket should be secured to the mounting truss or structure using a standard mounting clamp. Please note that when hanging the unit a safety cable should also be used.
SETTING UP WITH A DMX512 CONTROLLER 2.3-1 DMX512 ADDRESSING WITHOUT ID ADDRESSING (STAGE 1 MODE) Connect the DMX512 controller to the units in series. Each unit has 9 DMX channels so the DMX Addresses should increase by increments of 9 (e.g. 1,10,19,28...) The ID address has not been set so therefore when using the controller Ch9 must be inactive ( CH9=0 ).
Page 9
Example: DMX Addr.1 DMX Addr.1 DMX Addr.1 DMX Addr.10 DMX Addr.10 DMX Addr.10 ID Addr.1 ID Addr.2 ID Addr.3 ID Addr.1 ID Addr.2 ID Addr.3 ... . DMX512 The figure above shows a simple DMX layout CONTROLLER which has used three units at each DMX address.
DISPLAY PANEL OPERATION BASIC MENU ENTER DOWN MENU scroll through the main menu or exit from the current menu or function ENTER Enter the currently selected menu or confirm the current function value scroll 'UP' through the menu list or increase the value of the current function DOWN scroll 'DOWN' through the menu list or decrease the value of the current function 3 DISPLAY PANEL OPERATION...
Page 11
MENU MENU STATIC 000~255 GREN 000~255 BLUE 000~255 STRB 000~020 AUTO AUTO 1 custom 1 AUTO 2 custom 2 AUTO 3 custom 3 AUTO 4 custom 4 AUTO 5 custom 5 AUTO 6 custom 6 AUTO 7 custom 7 AUTO 8 custom 8 AUTO 9 custom 9...
Page 12
STATIC MENU STATIC 000~255 GREN 000~255 BLUE 000~255 STRB 000~020 STATIC Select GREN BLUE STRB to set the value AUTO MENU AUTO AUTO 1 custom 1 AUTO 2 custom 2 AUTO 3 custom 3 AUTO 4 custom 4 AUTO 5 custom 5 AUTO 6 custom 6...
Page 13
MENU SLAVE Enter to choose SLAVE working mode PERSON MENU PERSON STAGE1 ARC1 ARC1+D PERSON Enter PERSON and select STAGE1 ARC1 ARC1+D DMX mode MENU 001~066 Enter ID and set the ID address 001~066 EDIT MENU EDIT custom 1 scene 01 000~255 GREN 000~255 custom 2...
Page 14
3.10 SETTINGS MENU SETTINGS ON/OFF Reset to Factory? Up load custom? Choose ON / OFF to open or close ID Reset to Factory? This function will reset all setting to the original factory setting Up load custom? Select Up load custom? to upload the custom programs from the current MASTER unit to the SLAVE units 3.11...
USING A DMX512 CONTROLLER BASIC ADDRESSING Connect all of the units in series using standard DMX512 signal cable or the IP65 rated cable provided. Set the DMX512 address in the DMX menu. It is possible to have the same DMX address or independent addresses for each fixture. CHANNEL ASSIGNMENT Note: This product have three DMX512 channel configuration: STAGE 1...
Page 16
CHANNEL VALUE FUNCTION AUTO No function AUTO 1 AUTO 2 AUTO 3 AUTO 4 AUTO 5 AUTO 6 AUTO 7 AUTO 8 AUTO 9 AUTO 10 CUSTOM 1 CUSTOM 2 CUSTOM 3 CUSTOM 4 CUSTOM 5 CUSTOM 6 CUSTOM 7 CUSTOM 8 CUSTOM 9 CUSTOM 10...
Page 17
CHANNEL VALUE FUNCTION ID20 ID21 ID22 ID64 ID65 ID66 ARC 1 CHANNEL VALUE FUNCTION GREEN BLUE ARC 1+D CHANNEL VALUE FUNCTION MASTER DIMMER GREEN BLUE 4 USING A DMX512 CONTROLLER 2008.8.13...
Page 18
BASIC INSTRUCTIONS FOR DMX512 OPERATION (STAGE 1) MASTER DIMMER CH1 controls the intensity of the currently projected color When the slider is at the highest position (255) the intensity of the output is the maximum RED, GREEN & BLUE COLOR SELECTION CH2, CH3 &...
APPENDIX TROUBLE SHOOTING LED MODULE SITUATION CAUSE ACTION PART ORDER NUMBER 1) Power connection error 1) Check all power connections 2) Power switch damaged 2) Replace power switch 16-03-0030-04 No display 3) Display board damaged 3) Replace display board 26-2A-LED307DI-00 4) Fuse damaged 4)Replace the Fuse 1) Keyboard damaged...
