4
USING A DMX512 CONTROLLER
4.1

BASIC ADDRESSING

Connect all of the units in series using standard DMX512 signal cable or the IP65 rated cable
provided.
Set the DMX512 address in the DMX menu.
It is possible to have the same DMX address or independent addresses for each fixture.
4.2

CHANNEL ASSIGNMENT

Note: This product have three DMX512 channel configuration:
ARC 1+D
STAGE 1
3 DISPLAY PANEL OPERATION
, RGB+D
and
RGB+DS
13
STAGE 1
, ARC 1
2009.12.9
,
