APPENDIX
5.1 TROUBLE SHOOTING
LED MODULE
SITUATION
No display
LED MODULE on,
but no control
from display
LEDs of the same
color are not lit
LED module on,
LEDs of all colors
are not lit
Display normal,
but no response
to DMX 512
controller
5 APPENDIX
CAUSE
1) Power connection error 1) Check all power connections
2) Power switch damaged 2) Replace power switch
3) Display board damaged 3) Replace display board
4) Fuse damaged 4)Replace the Fuse
1) Keyboard damaged 1) Replace keyboard
2) Display board damaged 2) Replace display board
LED PCB damaged Check and Replace PCB board
1) Replace main PCB board
1) MAIN PCB damaged
2) Replace PCB board
2) LED PCB damaged
1) Signal connection error 1) Check and replace signal cable
2) DMX Address error 2) Check and reset DMX address
3) Check and reset the working mode
3) Master & slave mode error
4) ID error
4) Check and reset ID address
17
ACTION PART ORDER NUMBER
16-03-0030-04
26-2A-LED307DI-00
26-2A-LED307DI-00
26-2A-LED307DI-00
26-2A-307LED-00
26-2A-LED307DI-00
26-2A-307LED-00
2008.8.13
