Summary of Contents for Briteq BT-THEATRE 250EZ Mk2
-
Page 3: Before Use
• BT-THEATRE 150EZ Mk2: 150watt LED, warm white 3200K, zoom: 8°→52° beam angle • BT-THEATRE 250EZ Mk2: 250watt LED, warm white 3200K, zoom: 14°→54° beam angle • Excellent photometric characteristics: CRI / Ra >97, TLCI >98, CQS >94, Rf >93, Rg >100 ! •... -
Page 4: Safety Instructions
• Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ 2/13 BT-THEATRE 150EZ/250EZ Mk2... - Page 5 PC! Instead, this USB-connector makes it very easy to add wireless DMX to the ® unit! Just add the (optional) WTR-DMX DONGLE from BRITEQ and you will get wireless DMX! Moreover, you will be able to connect other DMX-controlled equipment to the DMX-...
-
Page 6: Overhead Rigging
Used to set the desired channel mode. (on RDM-compatible controllers this option can be set remotely) • Press the ▲/▼ buttons until the desired function is showing on the display. • Press the ENTER button: the values can be changed • Use ▲/▼ buttons to select the desired mode: BRITEQ 4/13 BT-THEATRE 150EZ/250EZ Mk2 ®... - Page 7 Used to configure different parameters if the projector. NO DMX Mode Used to set how the projector reacts when the DMX-signal disappears. • Press the ▲/▼ buttons until the desired function is showing on the display. BRITEQ 5/13 BT-THEATRE 150EZ/250EZ Mk2 ®...
- Page 8 Remark: The default value (1’200 Hz) gives excellent dimming performance with very low dimmer noises. FOCUS Preset Used to set the standard beam angle when a DMX-mode without focus control is selected. • Press the ▲/▼ buttons until the desired function is showing on the display. BRITEQ 6/13 BT-THEATRE 150EZ/250EZ Mk2 ®...
-
Page 9: Display Set
• Use ▲/▼ buttons to select one of these options: • Celcius: LED-temperature is shown in degrees Celcius °C. • Fahrenheit: LED-temperature is shown in degrees Fahrenheit F. • Press the ENTER button to confirm. BRITEQ 7/13 BT-THEATRE 150EZ/250EZ Mk2 ®... - Page 10 • Press the ▲/▼ buttons until the desired function is showing on the display. • Press the ENTER button: • No errors: display shows NONE • Errors to report: the error will be shown on the display so you can take action. BRITEQ 8/13 BT-THEATRE 150EZ/250EZ Mk2 ®...
-
Page 11: Other Setup Functions
• Press the ENTER button: the display shows the firmware version. Note: The firmware of this unit can be upgraded using our special “Firmware Updater 2” (separately available from Briteq). More information about this can be found in the user manual of the firmware updater or our website: https://briteq-lighting.com/firmware-updater-2 RDM UID Shows the unique RDM identification code of the projector. - Page 12 ID. • The DMX-controller asks each RDM device for some basic data so it knows which devices are connected. The projector will respond: • Device name: BT-THEATRE 150EZ Mk2 (or BT-THEATRE 250EZ Mk2) • Manufacturer: ® Briteq • Category: LED Dimmer •...
- Page 13 Random strobe (slow→fast) 136-255 Small → large beam 000-255 Focus Remark: Remote “Focus reset” will be activated when the following DMX-values are received during 5seconds: CH1 = 001 * CH3 = 002 * CH4 = 003 BRITEQ 11/13 BT-THEATRE 150EZ/250EZ Mk2 ®...
-
Page 14: Maintenance
Lamp (250EZ Mk2): LED, 250W Warm white CCT 3000-3200K - CRI >97 electronic zoom 8°→52° Beam Angle (150EZ Mk2): electronic zoom 14°→54° Beam Angle (250EZ Mk2): IP-Rating: IP20 Size: See drawing Weight: 9 kg BRITEQ 12/13 BT-THEATRE 150EZ/250EZ Mk2 ®... - Page 15 LED Source: 14’000 lm - Average lumen output: 5’500 lm @ 14° - 12’330 lm @ 54° The information might be modified without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ...
