P E
OWER OVER
The NetVanta 1230 PoE Series (P/Ns 1700595G1, 1700599G1, 1700599G2) are Power over
Ethernet (PoE) switches. PoE switches provide the ability to detect attached powered devices
(PDs) and deliver 48 VDC to the PD via existing Ethernet cabling. The NetVanta 1230 PoE Series
is fully compliant with the IEEE 802.3af PoE standards. By default, the PoE switches discover
and provide power to IEEE-compliant PDs.
To disable power detection and supply, use the power inline never command in the CLI. To
disable power detection and supply from the GUI, select the Ports page. Then select a single port
from the list (e.g., switchport 0/1). This will bring up the port detail page for switchport 0/1. On
this page, there is a check box to disable power detection.
C
ONFIGURE THE
The following steps create an IP address and subnet mask for the virtual local area network
(VLAN) interface vlan 1. If you are not sure what IP address to assign, please contact your
network administrator.
1. At the # prompt, enter config terminal.
2. At the (config)# prompt, enter interface vlan 1 to access the configuration parameters for
the VLAN interface.
3. Enter ip address 10.26.12.12 255.255.255.0 to assign an IP address to the VLAN interface
using a 24-bit subnet mask.
4. Enter no shutdown to activate the VLAN interface to pass data.
5. Enter exit to return to the Global Configuration mode.
6. Enter ip default-gateway 192.168.1.254 to add a default gateway. 192.168.1.254 is the
next-hop IP address to which the AOS unit should send traffic not destined for the local
network. You will need to enter the proper gateway for your network. This information is
typically provided by an Internet service provider (ISP) or local network administrator.
7. Enter do write memory to save the current configuration.
The configuration parameters used in the examples outlined in this
document are for instructional purposes only. Please replace all
underlined entries (
your application.
E T
NABLE ELNET
The following steps enable user login parameters for Telnet access by changing the password
from the default (password) and enabling security login on Telnet lines.
1. Verify that the prompt of your unit displays (config)#.
2. Enter line telnet 0 4 to change the configuration parameters for the Telnet sessions.
3. Enter login to prompt users with a login prompt for Telnet access.
4. Enter password adtran to change the login password for the Telnet sessions.
5. Enter exit to return to the Global Configuration mode.
6. Verify that the prompt of your unit displays (config)#.
7. Enter do write memory to save the current configuration.
Quick Start Guide, 61700594G1-13B, November 2011
THERNET
U ' IP A
NIT S DDRESS
example
U L A
SER OGIN
) with your specific parameters to configure
CCESS
3
