ADTRAN NetVanta 1234 Specifications

Product Features

24/48-port auto-sensing
■
10/100Base-T managed
Layer 2 Ethernet switch
4 Gigabit uplink ports
■
Non-blocking, up to 17.6 Gbps
■
switching capacity
802.1Q tagged and port-
■
based Virtual Local Area
Networks (VLANs)
Support for up to 255
■
active VLANs
802.1p and DiffServ
■
prioritization with four
queues per egress port
Link aggregation, LLDP
■
and LLDP-MED
Weighted Round Robin (WRR)
■
and WRR + expedite
802.1D Spanning Tree and
■
802.1w Rapid Spanning
Tree support
DHCP address management
■
RADIUS authentication
■
Port mirroring
■
TFTP/FTP firmware upgrades
■
Broadcast, Unicast, and
■
Multicast storm control
Wi-Fi Access Controller
®
■
for centralized management
of NetVanta Wireless
Access Points (WAPs)
Cable diagnostics identifies
■
cable length and detects
shorts or open twisted pair
Familiar Command Line
■
Interface (CLI)
Web-based Graphical User
■
Interface (GUI)
Limited Lifetime Warranty
■
NetVanta 1234/1238
Layer 2 Fast Ethernet Switches
The NetVanta 1000 Series of managed,
®
Layer 2, Ethernet switches is designed for
fast, secure, cost-effective LAN switching.
These scalable, full-featured business-class
switches are perfect for VoIP applications by
using robust Quality of Service (QoS) features,
protecting the organization with advanced
security capabilities, and ease of management
with an easy to use Web-GUI and familiar
Command Line Interface (CLI).
Hardware
The NetVanta 1234 and 1238 rackmount
switches support 24 and 48 10/100Base-T
Ethernet ports with auto-rate, auto-duplexing,
and MDI/MDI-X sensing. The NetVanta 1234/
1238 also supports four Gigabit ports for
uplink or stacking capability.
Standard-based Protocols
Based on the ADTRAN Operating System
®
(AOS), these devices offer support for Link
Aggregation (802.3ad), Port Mirroring, Port-
based switching features including Broadcast
Storm Control, Spanning Tree (802.1D) and
Rapid Spanning Tree (802.1w) for faster
network convergence, link redundancy, and
recovery from topology changes. Link Layer
Discovery Protocol (LLDP) auto-discovers
neighboring Ethernet devices, simplifying
integration into multi-vendor environments.
VLANs
All NetVanta switches support 802.1Q
trunking and up to 255 port-based VLANs
to allow network managers to separate
broadcast domains for efficient network
performance and traffic control.
Security
Rest assured, with the NetVanta 1234
and 1238 your network is protected. These
products also offer a variety of data security
features including multilevel user passwords,
Smart Solutions for a
Connected World.
Secure Shell (SSH) and Secure Socket Layer
(SSL) for encrypted user login, and Access
Authentication and Authorization (AAA)
for authentication with a RADIUS, RSA
SecurID and TACACS+.
Quality of Service (QoS)
NetVanta switches also support QoS to
ensure network managers have the ability to
prioritize mission critical traffic like VoIP and
control network congestion. The NetVanta
1000 Series offers 802.1p and DiffServ Class
of Service (CoS). Each switch supports frame
tagging, as well as enforcement of tagged
traffic received from trusted sources. Four
egress queues (per port) are available for
assigning traffic priorities using Weighted
Round Robin (WRR).
Administration
The AOS offers both a Command Line
Interface (CLI) that mimics the widely
deployed, industry de facto standard and an
intuitive web-based GUI with step-by-step
configuration wizards. For a centralized
enterprise-wide management scheme,
ADTRAN offers n-Command
scalable software suite for managing firm-
ware revisions, push firmware upgrades and
configuration changes, backup and restore
configurations, and manage security policies
and Access Control Lists (ACLs).
NetVanta 1000 Series of Ethernet switches
are easily coupled with other ADTRAN
products including access routers, Wireless
Access Points, IP Business Gateways, IP
phones, and VoIP telephony solutions. All
these solutions are backed by ADTRAN's
industry-leading support, services, and
industry-leading warranty.
