1. Connect the DB-9 (male) connector of your serial cable to the CONSOLE port located on
the either the front or rear panel of the unit.
2. Connect the other end of the serial cable to the PC.
Many PCs do not come with a standard serial port. A universal serial
bus (USB) to serial adapter can be used instead. The drivers for the USB
to serial adapter must be installed according to the manufacturer's
instructions. If the USB to serial adapter is not properly installed on your
PC, you will not be able to communicate with the AOS unit and you
should seek support from the USB to serial adapter manufacturer.
3. Provide power to the unit as appropriate. Refer to the
Switch Hardware Installation Guide
http://kb.adtran.com
4. Once the unit is powered up, open a VT100 terminal session using the following settings:
9600 baud, 8 data bits, no parity bits, 1 stop bit, and no flow control. Press <Enter> to
activate the AOS CLI.
5. Enter enable at the > prompt and enter the Enable mode password when prompted. The
default password is password.
You can also access the CLI from a Telnet client. In order to do this, you must know the IP
address of the AOS device. If you do not know the unit's IP address, you must use the CONSOLE
port to access the CLI. To access the CLI using a Telnet client, follow these steps:
1. Connect the unit to your PC using any Ethernet switchport on the front of the unit and an
Ethernet cable.
2. Open a Telnet client on your computer. You can access the Telnet client by navigating to
Start > Run and entering telnet 10.10.10.1 (Windows® XP). If you are running Windows
Vista, you will need to turn on the Telnet client before you access it. To do this, navigate to
Start > Control Panel > Programs and Features > Turn Windows features on or off >
Telnet Client Option and select OK. 10.10.10.1 is the default unit IP address. If you have
changed your unit's IP address, you will need to enter that address.
3. Enter enable at the > prompt and enter the enable password when prompted. The default
password is password.
C CLI C
OMMON
The following are common CLI commands and tips for getting started with the CLI.
• Entering a question mark (?) shows contextual help and options. For example, entering ? at
the prompt will show all commands available from that prompt.
• To view interface statistics, enter show interface <interface type> <interface number>.
• To view the current configuration, enter show running-config.
• To view all the IP addresses currently configured, enter show ip interface brief.
• To view the AOS version, serial number, and other information, enter show version.
• To save the current configuration, enter write.
R P
EDUNDANT OWER
The NetVanta 1238 PoE Redundant Power Supply (RPS) (P/N 1700599G2) switch provides a
redundant power supply receptacle on the rear panel of the unit. The NetVanta 1110 RPS (P/N
1700531G1) is housed in a 1U high rack mountable metal enclosure and includes a universal AC
power supply. The NetVanta 1110 RPS provides a redundant +12 VDC for powering the switch
processor and hardware and -48 VDC for PoE backup.
2
(ADTRAN's Knowledge Base article 2517) online at
for more details.
OMMANDS
S
UPPLY
Copyright © 2011 ADTRAN, Inc. All Rights Reserved.
NetVanta 1230 Series Fast Ethernet
