DTR-4.9 3 7 63 1515 0 Ref. No. 4071 SERVICE MANUAL SERVICE MANUAL May, 2008 AV RECEIVER DTR-4.9 MODEL RC-711M Black model L 13942296513 B MDD 120V AC, 60Hz SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
Page 2
DTR-4.9 3 7 6 3 1 5 1 5 0 EXPLODED VIEWS-1 A303 x 6 pcs. A017 A075 A014 x 4 pcs. A053 A012 P101 A016 x 38 pcs. A022 A032 A070 A301 A020 A027 Refer to x 2 pcs.
Page 4
DTR-4.9 3 7 6 3 1 5 1 5 0 BLOCK DIAGRAMS-1 AUDIO SECTION TUNER UNIT AUDIO ANALOG Q5501 R2S15211FP FRONT L SELECTOR / TONE / VOLUME PHONES FRONT R POWER AMPLIFIER AUDIO DIGITAL MIC AMP. TONE +29dB SETUP MIC...
DTR-4.9 3 7 63 1515 0 BLOCK DIAGRAMS-2 VIDEO / HDMI SECTION NAHDM-9565 HDMI TMDS3 TMDS DDC3 IN 3 RPWR3 HPD3 HP DET HDMI Digital Video TMDS2 TMDS TMDS TMDS TMDS Q8162 DDC2 SII9185 RPWR IN 2 Q8501 Q8401...
Page 6
DTR-4.9 3 7 6 3 1 5 1 5 0 Refer to following table about the parts displayed by mark " LIST ". SCHEMATIC DIAGRAMS-1 (SD-1) MODEL No. ---> DTR-4.9 DTR-5.9 DTX-5.9 TYPE ---> AUDIO INPUT SECTION MICROPROCESSOR PCB...
DTR-4.9 3 7 6 3 1 5 1 5 0 DSP/HDMI PCB ZONE 2 / IR PCB LIST SIRIUS/DOCK TERMINAL PCB SCHEMATIC DIAGRAMS-3 (SD-3) To NAETC-9452 To NAHDM-9565 LIST To NARF-9463 LIST LIST To TUNER UNIT To NALAN-9465 SD-8 : F1...
Page 9
DTR-4.9 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS-4 (SD-4) VIDEO SECTION P3007A NAVD-9467 Refer to following table about the parts displayed by mark " LIST ". LIST +12V MODEL NO. ---> DTR-4.9 DTR-5.9 DTX-5.9 Q9101...
Page 10
DTR-4.9 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS-5 (SD-5) LIST NATRM-9428 SPEAKER TERMINAL / POWER SUPPLY SECTION NAETC-9449 ZONE 2 SPEAKER TERMINAL PC BOARD <Note> HEADPHONE JACK 1. NC = No mount of parts. PC BOARD 2.
Page 11
DTR-4.9 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS-6 (SD-6) DISPLAY SECTION NADIS-9444 DISPLAY PC BOARD Q7002 FL TUBE 16BT128GNK REMIN NOTE FLDRST THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY FLDCS FLDCLK REPLACE ONLY WITH PART NUMBER SPECIFIED.
DTR-4.9 3 7 63 1515 0 SCHEMATIC DIAGRAMS-10 WAVEFORM SECTION-1/3 Digital Audio Waveform Part <Notes> 1. WF01 is short for Waveform-01 . 2. Refer to SD-3 (SCHEMATIC DIAGRAMS-3) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
Page 16
DTR-4.9 3 7 63 1515 0 SCHEMATIC DIAGRAMS-11 WAVEFORM SECTION-2/3 Video Waveform Part Video source color and pattern <Notes> 1. WF21 is short for Waveform-21 . 2. Refer to SD-4 (SCHEMATIC DIAGRAMS-4) for the location of each waveform on circuit.
Page 17
DTR-4.9 3 7 63 1515 0 SCHEMATIC DIAGRAMS-12 WAVEFORM SECTION-3/3 FL Driver IC Control Waveform Part <Notes> 1. WF61 is short for Waveform-61 . 2. Refer to SD-6 (SCHEMATIC DIAGRAMS-6) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
Page 18
DTR-4.9 3 7 63 1515 0 PACKING PROCEDURE A801 A804 A807 A822 A823 A805 A802 A824 A803 A806 A604 P901 A605 A607 L 13942296513 Right side marking Front side A603 marking A821 A605 Front side A606 A702 A601 (L & R)
Page 38
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-3 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-3/5 TERMINAL DESCRIPTION External Memory Interface (EMIF) Address and Control Pin Name Pin No. Type Description EM_A[0] EMIF Address Bus EM_A[1]...
Page 39
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-4 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-4/5 TERMINAL DESCRIPTION McASP0, McASP1, McASP2, and SPI1 Serial Ports Pin Name Pin No. Type Description AHCLKR0/AHCLKR1 McASP0 and McASP1 Receive Master Clock...
Page 40
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-5 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-5/5 TERMINAL DESCRIPTION Clocks Pin Name Pin No. Type Description OSCIN 1.2-V Oscillator Input OSCOUT 1.2-V Oscillator Output OSCVDD Oscillator 1.2-V VDD tap point (for filter only)
Page 41
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-6 Q281 : M12L64164A-7TG ( 1M x 16 Bit x 4 Banks Synchronous DRAM ) BLOCK DIAGRAM PIN LAYOUT TOP VIEW Clock Generator DQ15 Bank D VDDQ VSSQ...
Page 45
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-10 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-3/4 TERMINAL DESCRIPTION Name Pin No. Function AD0/CS Address Bit 0 (I2C)/Control Port Chip Select (SPI) (INput) - AD0 is a chip address pin in I2C mode; CS is the chip select signal in SPI mode.
Page 46
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-11 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-4/4 TERMINAL DESCRIPTION Name Pin No. Function CL_SDOUT CODEC Serial Data Output (Output) - Output for two's complement serial audio data the internal and external ADCs.
Page 48
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-13 Q3001 : AN15880A (Video SW for Receiver with Multi-signal)-2/3 TERMINAL DESCRIPTION (1/2) Pin No. Pin name Type Descripion Input Luminance signal input 1 Input Luminance signal input 2...
Page 49
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-14 Q3001 : AN15880A(Video SW for Receiver with Multi-signal)-3/3 TERMINAL DESCRIPTION (2/2) Pin No. Pin name Type Description No connection CYOUT1 signal output CYOUT1 Output Ground GND4 Ground...
Page 50
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-15 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Bass &...
Page 51
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-16 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-2/3 BLOCK DIAGRAM AND PIN CONFIGURATION 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25...
Page 52
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-17 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-3/3 TERMINAL DESCRIPTION PIN No. Name Function 19,17, FROUT,FLOUT, 14,12, 6-OUT,5-OUT, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel...
Page 53
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-18 Q7003 : M66005-0001AHP (FL Tube Driver) BLOCK DIAGRAM Display code RAM SEG00 CG ROM Bank 1 : 8bit x 16 (35bit x 160) Bank 2 : 8bit x 64...
Page 54
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-19 Q8162 : SiI9185ACTU (Three Input, Single Output Deep Color HDMI Switch)-1/3 BLOCK DIAGRAM R0X0+/- EDID Configuration R0X1+/- I C Switch Logic R0X2+/- R0XC+/- Serializer / TX0+/- Tx Driver...
Page 55
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-20 Q8162 : SiI9185ACTU (Three Input, Single Output Deep Color HDMI Switch)-2/3 TERMINAL DESCRIPTION System switching Pin Name Pin # Description DSDA0, Input / DDC I C Data for respective port.
Page 56
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-21 Q8162 : SiI9185ACTU (Three Input, Single Output Deep Color HDMI Switch)-3/3 TERMINAL DESCRIPTION Differential Signal Data Pins Pin Name Pin # Description RX0+ 20, 41, 62 Input TMDS input data pairs.
Page 59
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-24 Q8401 : SiI9034CTU (HDMI Transmitter)-3/4 TERMINAL DESCRIPTION Video and Audio Input pins Pin Name Pin # Description Input These are the lower 12 bits of the 24-bit pixel bus.
Page 60
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-25 Q8401 : SiI9034CTU (HDMI Transmitter)-4/4 TERMINAL DESCRIPTION Configuration / Programming Pins Pin Name Pin # Description Input Hot Plug Detect Input. RSVDL Input Reserved for use by Silicon Image and must be tied LOW.
Page 63
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-28 Q8051 : SiI9013 ( HDMI Receiver)-3/4 TERMINAL DESCRIPTION Digital video Output Pins Pin Name Pin # Description Pin Name Pin # Description Output Output Output Output Output...
Page 64
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-29 Q8051 : SiI9013 ( HDMI Receiver)-4/4 TERMINAL DESCRIPTION Configuration / Programming Pins Pin Name Pin # Description Output Interrupt Output. RESET# Input Reset Pin. Active LOW. Note that this pin must be dynamically controlled as part of normal operation.
Page 65
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-30 Q6310 : M61540FP (6ch Electronic Volume with 5 Input Selector)-1/2 BLOCK DIAGRAM MCU I/F DVDD Gain Gain Control Control SLOUT BASL2 SROUT BASL1 Gain Gain Gain Gain...
Page 66
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-31 Q6310 : M61540FP (6ch Electronic Volume with 5 Input Selector)-2/2 TERMINAL DESCRIPTION Pin No. Pin Name Description 1, 8, 25, 32 AGND Analog Ground Input pin of L channel (Multi)
Page 67
DTR-4.9 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-32 Q6311 : ICL3221ECVZ (RS-232 Transmitters / Receivers) BLOCK DIAGRAM TOP VIEW FORCEOFF T1OUT FORCEON T1IN INVALID R1IN R1OUT L 13942296513 TERMINAL DESCRIPTION Pin Name Description System power supply input (3.0V to 5.5V).
DTR-4.9 3 7 63 1515 0 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol.
Page 73
DTR-4.9 3 7 63 1515 0 SERVICE PROCEDURE-2 5. To check version of Main microprocessor, DSP and Network microprocessor FW 1. Press and hold down Display button, then press On/Standby button when the unit is power on. The main microprocessor version will be displayed on Front Display for about 3 seconds.
Page 74
DTR-4.9 3 7 63 1515 0 OPERATION CHECK-1 SPEAKER PROTECT-1 Circuit configuration The unit go into protect mode when either of thermal detection, dc voltage detection or current detection circuit operates. Power amplifier VPRO : DC voltage detection IPRO : Current detection...
Page 75
DTR-4.9 3 7 63 1515 0 OPERATION CHECK-2 SPEAKER PROTECT-2 DC Voltage detection check [When] 1. Exchange power transistors (Q6050 - Q6054, Q6060 - Q6064). 2. Exchange amplifier PC board ass'y (NAAF-9424). [Procedure] Note : No load. No input.
Page 76
DTR-4.9 3 7 63 1515 0 OPERATION CHECK-3 SPEAKER PROTECT-3 Current detection check [When] 1. Exchange power transistors (Q6050 - Q6054, Q6060 - Q6064). 2. Exchange amplifier PC board ass'y (NAAF-9424). [Procedure] Notes : No input. Do not check two or more channels at the same time.
Page 77
DTR-4.9 3 7 63 1515 0 OPERATION CHECK-4 POWER SUPPLY CONTROL Configuration The power supply voltage of +/-B1 for power amplifier is changed by the relays (RL6901, 6902). Output sensor RL6901 Power amplifier S1H+ +22V S1H- Thermal sensor Q6380...
DTR-4.9 3 7 63 1515 0 FIRMWARE UPDATE-1 GENERAL To check version of Main Microprocessor, DSP and Video FW 1. Press and hold down Display Display button, then press On/Standby On/Standby button when the unit is power on. The main microprocessor version will be displayed on Front Display for about 3 seconds.
Page 79
DTR-4.9 3 7 63 1515 0 FIRMWARE UPDATE-2 UPDATE OF MAIN MICROPROCESSOR-2/2 Update Procedure 1. Double click "Update.exe Update.exe" in the unzipped folder "Update_SR606Main1.2.zip” (Folder name depends on the version). The following window will appear. Updater COM Port(C) Log Visible Firmware Read Result 001.
Page 80
DTR-4.9 3 7 63 1515 0 FIRMWARE UPDATE-3 UPDATE OF DSP Preparation for update Update is done by playback of CD-R in a CD player. Tool 1. Blank CD-R : 1pc, PC (Personal computer with CD-R writer) 2. Writing soft : “CD_SR6060_08213A.wav” (File name depends on the version.) <Note>...
DTR-4.9 3 7 63 1515 0 DEBUG MODE-1 DSP DEBUG MODE-1 The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode. This information will help to analysing digital audio no sound trouble.
Page 82
DTR-4.9 3 7 63 1515 0 DEBUG MODE-2 DSP DEBUG MODE-2 Content of Display (Continued) DSP Port DSP Decode This figure is displayed in hexadecimal form. o = Decode OK If this is transformed to binary form, each bit indicates x = Decode NG the following DSP port status.
Page 83
DTR-4.9 3 7 63 1515 0 DEBUG MODE-3 DSP DEBUG MODE-3 Trouble Shooting by DSP DEBUG MODE (Continued) Symptom on FL display Cause of trouble Remedy Digit No. on FL Continue to display "1" Interface between DSP and MPU is no good.
Page 84
DTR-4.9 3 7 63 1515 0 DEBUG MODE-4 SERVICE INFORMATION MODE Trouble Shooting by Displaying Service information This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off.
Page 85
DTR-4.9 3 7 63 1515 0 DEBUG MODE-5 HDMI DEBUG MODE-1/2 HDMI-related operations can be checked to some extent by displaying HDMI debug mode. To enter this mode Hold down Display Display button for 3 seconds. Information display will last for about 8 seconds.
Page 86
DTR-4.9 3 7 63 1515 0 DEBUG MODE-6 HDMI DEBUG MODE-2/2 FL segment No. ---> Video Input Format Status Description Video signal route : Source Device HDMI Through Video resolution is not Determined Error State ---> Remedy Input Input Description --->...
Page 87
HDMI VIDEO SETUP TROUBLE This trouble shooting map focuses on the video setup errors regarding HDMI. For reference, read DTR-4.9 Owner’s Manual. Analysis written below is of typical cases. So, more detailed check may need in actual cases. Video trouble...
Page 88
HDMI AUDIO SETUP TROUBLE This trouble shooting map focuses on the audio setups and connections regarding HDMI. For reference, read DTR-4.9 Owner’s Manual. Analysis written below is of typical cases. So, more detailed check may need in actual cases. Audio trouble...
DTR-4.9 3 7 63 1515 0 ADJUSTMENT PROCEDURE-1 IDLING CURRENT ADJUSTMENT [When] 1. Exchange Power transistor (Q6050 - Q6054, Q6060 - Q6064). 2. Amplifier PC board (NAAF-9424). [Procedure] Refer to "ADJUSTMENT PROCEDURE-2 " for the adjustment points and the test points.
Page 90
DTR-4.9 3 7 63 1515 0 ADJUSTMENT PROCEDURE-2 IDLING CURRENT ADJUSTMENT Adjustment points and the test points Front side Adjustment point Test point (Trimming resistor) P6086 R6044 P6084 Surround Amplifier PC board Right ch (NAAF-9424) P6084 R6041 P6081 P6081...
Page 91
3 7 6 3 1 5 1 5 0 1/76 PAGE DTR-4.9 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
Page 94
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 4/76 PAGE Q6062 or MP130S-P 2203676 EXPLODED Q6063 MP130S-O 2203673 EXPLODED Q6063 or MP130S-Y 2203674 EXPLODED Q6063 or MP130S-P 2203676 EXPLODED Q6064 MP130S-O 2203673 EXPLODED Q6064 or MP130S-Y 2203674 EXPLODED Q6064 or MP130S-P 2203676...
Page 95
ENG06507QFUS 240156 EXPLODED U45 or TUNER UNIT FAE385-A11US 240152 EXPLODED DTR-4.9 PC BOARD PARTS LIST AMPLIFIER PC BOARD (NAAF-9424-1E) PCB1 TRANS. SEC. TERMINAL PC BOARD (NAPS-9425-1E) PCB1 THERMAL SENSOR PC BOARD (NAETC-9426-1E) PCB1 L 1 3 9 4 2 2 9 6 5 1 3 PCB1 CIRCUIT NO.
Page 99
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 9/76 PAGE D6703 ZENER D UDZ3.3B 224490330R2 PCB1 D6703 or ZENER D UDZS3.3B 224550330R2 PCB1 D6704 ZENER D UDZ3.3B 224490330R2 PCB1 D6704 or ZENER D UDZS3.3B 224550330R2 PCB1 D6901 DIODE D10XB60H 22380337 PCB1...
Page 100
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 10/76 PAGE C5554 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5555 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5556 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5557 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5558 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5559...
Page 101
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 11/76 PAGE C5667 UTSP C CE04W25V-220M(UTSP) 397552217T PCB1 C5670 UTSP C CE04W50V-1M(UTSP) 397580107T PCB1 C5671 UTSP C CE04W50V-1M(UTSP) 397580107T PCB1 C5672 UTSP C CE04W25V-220M(UTSP) 397552217T PCB1 C5673 UTSP C CE04W25V-220M(UTSP) 397552217T PCB1 C5674...
Page 102
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 12/76 PAGE C6050 TF C ECQ-B50V-103J 374721034T PCB1 C6051 TF C ECQ-B50V-103J 374721034T PCB1 C6052 TF C ECQ-B50V-103J 374721034T PCB1 C6053 TF C ECQ-B50V-103J 374721034T PCB1 C6054 TF C ECQ-B50V-103J 374721034T PCB1 C6630...
Page 103
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 13/76 PAGE R5514 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5515 C-CARBON R RN72K1J-222JE 435032224R1 PCB1 R5516 C-CARBON R RN72K1J-222JE 435032224R1 PCB1 R5517 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5518 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5519...
Page 104
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 14/76 PAGE R5575 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5576 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5577 C-CARBON R RN72K1J-473JE 435034734R1 PCB1 R5578 C-CARBON R RN72K1J-473JE 435034734R1 PCB1 R5579 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5585...
Page 105
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 15/76 PAGE R5617 C-CARBON R RN72K1J-222JE 435032224R1 PCB1 R5618 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5619 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5620 C-CARBON R RN72K1J-101JE 435031014R1 PCB1 R5623 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5624...
Page 106
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 16/76 PAGE R5822 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5823 METAL O R RS1WBJ-33 443623304T PCB1 R5824 METAL O R RS1WBJ-33 443623304T PCB1 R5831 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5832 C-CARBON R RN72K1J-000JE 435030004R1 PCB1...
Page 107
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 17/76 PAGE R6042 TRIM R N06HR2KBC 5210390T PCB1 R6043 TRIM R N06HR2KBC 5210390T PCB1 R6044 TRIM R N06HR2KBC 5210390T PCB1 R6050 CARBON R R16J-3.3K 417343324T PCB1 R6051 CARBON R R16J-3.3K 417343324T PCB1 R6052...
Page 108
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 18/76 PAGE R6140 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R6141 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R6142 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R6143 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R6144 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R6150...
Page 109
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 19/76 PAGE R6704 C-CARBON R RN72K1J-473JE 435034734R1 PCB1 R6706 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R6708 C-CARBON R RN72K1J-333JE 435033334R1 PCB1 R6709 C-CARBON R RN72K1J-562JE 435035624R1 PCB1 R6710 C-CARBON R RN72K1J-472JE 435034724R1 PCB1 R6902...
Page 110
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 20/76 PAGE P6603 WS CLAMP CB-71683(L=50) 260261 PCB1 P6900 CRIMP AS UL1015#18SIN-SVH 300 BLK 20799177UL PCB1 P6901 CRIMP AS CRIMP AS 2069925132UL PCB1 P6902 CRIMP AS CRIMP AS 2069925206UL PCB1 P6903 CRIMP AS UL1015#18SIN-SVH 200 YEL...
Page 111
http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 21/76 PAGE TRANS. SEC. TERMINAL PC BOARD (NAPS-9447-1D) PCB2 SETUP MIC JACK PC BOARD (NAETC-9448-1D) PCB2 HEADPHONE JACK PC BOARD (NAETC-9449-1D) PCB2 INLET PC BOARD (NAETC-9451-1D) PCB2 ZONE 2 / IR PC BOARD (NAETC-9452-1D) PCB2 PCB2 CIRCUIT NO.
