This section contains information about cables used in simple Vision MINI Xi
Smart Camera hardware configurations.
Note: Cable specifications are published for information only. Microscan
does not guarantee the performance or quality of cables provided by
other suppliers.
TABLE B–1.
Part Number
61-000153-02
61-000167-02
97-000012-01
99-000020-02
Vision MINI Xi Smart Camera Guide

Cable Specifications

Cable Part Numbers and Descriptions
Description

Cordset, Host, Serial, M12 12-Pin Socket to DB9 Socket, 1 M

Cordset, M12 12-Pin Socket to Flying Leads, 3 M

Power Supply, 90-254VAC, 24V, M12 12-Pin Socket

Photo Sensor, M12 4-Pin Plug, NPN, Dark On, 2 M
