Pages, Panels, and Widgets

Pages, Panels, and Widgets
The main area of CloudLink displays one of a number of pages. If there is more than one
page defined, you can switch between them by using the page selection buttons on the
application bar, or by using the arrow keys on your keyboard.
Each page is organized into a set of regions called panels. The following image shows an
empty page to demonstrate the arrangement of the panels on a page.
Note the names, which start with .panel-. It is not necessary to know these names to use
CloudLink; however they do have significance if there should be need for customization.
Customizing CloudLink requires the modification of CSS (Cascading Style Sheets). The
names shown correspond to the CSS class selector for that panel.
The purpose of the panels is to act as containers for a number of widgets. Each widget
has the ability to visualize and interact with one or more items of inspection data such as
Microscan Link values, inspection counters, timing information, or images.
Vision MINI Xi Smart Camera Guide F-5
