SPECIFICATION
Wingspan :
1,580mm.
Length
: 1,255 mm.
Weight
:
2.5kg.
Parts Listing required (not included).
Radio :
4 channels.
Servo :
4-5 servos.
Glow Engine : 46-55 cu.in. 2 stroke.
Instruction Manual book
Electric Motor: AXI 2826/10.
62.20 in.
Battery: 4-5 Cells-Li-Poly-14.8-18.5v- 5.000 mAh - 20 c .
49.41in.
Speed Control:
5.50lbs.
Propeller :
Recommended R.C: 4 channels with
60A.
13 x 6.
4-5 servos.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the renegade bh66 and is the answer not in the manual?

Questions and answers

Related Manuals for Black Horse Model renegade bh66

Summary of Contents for Black Horse Model renegade bh66

  • Page 1 Instruction Manual book SPECIFICATION Electric Motor: AXI 2826/10. Wingspan : 1,580mm. 62.20 in. Battery: 4-5 Cells-Li-Poly-14.8-18.5v- 5.000 mAh - 20 c . Length : 1,255 mm. 49.41in. Speed Control: 60A. Weight 2.5kg. 5.50lbs. Propeller : 13 x 6. Parts Listing required (not included). Recommended R.C: 4 channels with Radio : 4 channels.
  • Page 2 RENEGADE - Instruction Manual ITEM CODE:BH66 This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your RENEGADE. Use the parts listing below to identify all parts. WARNING. Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable of causing injury to people or property.

  • Page 3: Safety Precaution

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. SAFETY PRECAUTION. + This is not a toy + Be sure that no other flyers are using your radio frequency. + Do not smoke near fuel + Store fuel in a cool, dry place, away from children and pets.
  • Page 4 RENEGADE - Instruction Manual ITEM CODE:BH66 2. Using a modeling knife, remove the cov- ering servo tray. Remove covering C/A glue Servo tray 3. Drill 1,5mm pilot holes through the block Bottom side of wood for each of the four mounting screws provided with the servo.
  • Page 5 RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. INSTALLING THE AILERON CONTROL HORN. Electric wire 3x35mm. M3 lock nut. Nilon control clasp. 2 x 10 mm. Secure Control horn of Aileron 1. Using a ruler & pen to draw a straight line as below picture. Bottom side Repeat the procedure for the other wing Mark point...

  • Page 6: Installing The Aileron Linkages

    RENEGADE - Instruction Manual ITEM CODE:BH66 4. Install control horn as same as picture 2. Locate nylon control horn, nylon con- below. trol horn backplates . Bottom side 3. Drill through 6mm (diameter) the aileron using the control horn as a guide and screw the control horn in place.

  • Page 7: Joining The Wing Halves

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. Repeat the procedure for the other wing M2 lock nut. half. Snap keeper. M2 clevis. 2. Attach the clevis to the outer hole in the control horn. 3. Plug the aileron servo into the receiver and center the servo.

  • Page 8: Installing The Engine Mount

    RENEGADE - Instruction Manual ITEM CODE:BH66 INSTALLING THE ENGINE MOUNT. THERE ARE TWO OPTIONS: 1. ELECTRIC MOTOR 2. ENGINE MOUNT. OPTION 1: ELECTRIC MOTOR. 3. Test fit the dihedral brace into each wing half. The brace should slide in easily. 3 x 15mm Epoxy glue 3x 15mm...
  • Page 9 RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. Secure OPTION 2: ENGINE MOUNT. 4 x 25mm Tie wrap Tie wrap...
  • Page 10 RENEGADE - Instruction Manual ITEM CODE:BH66 FUEL TANK. INSTALLING THE STOPPER ASSEMBLY 1. The stopper has been pre-assembled at the factory. 2. Using a modeling knife, cut one length of Vent tube Fuel pick- up tube silicon fuel line (the length of silicon fuel line is calculated by how the weighted clunk should rest about 8mm away from the rear of the tank and move freely inside the tank).

  • Page 11: Installing The Engine

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. INSTALLING THE ENGINE. Locate the long piece of wire used for the throttle pushrod. One end of the wire has been pre-bend in to a “Z” bend at the factory. This “Z” bend should be inserted into the throttle arm of the engine when the engine is fitted onto Do not secure the tank into place perma- the engine mount.
  • Page 12 RENEGADE - Instruction Manual ITEM CODE:BH66 COWLING. 1. Slide the fiberglass cowl over the en- gine and line up the back edge of the cowl with the marks you made on the fuselage. 3 x 20mm Pushrod wire Trim and cut Secure Pushrod wire Bottom side...

  • Page 13: Installing The Spinner

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. 4. Install the muffler and muffler extension onto the engine and make the cutout in the cowl for muffler clearance. Connect the fuel and pressure lines to the carburetor, muffler Machine screw. and fuel filler valve. Right side INSTALLING THE SPINNER.

  • Page 14: Horizontal Stabilizer

    RENEGADE - Instruction Manual ITEM CODE:BH66 ELEVATOR INSTALLATION. SERVO INSTALLATION. 1. Install the rubber grommets and brass collets into the elevator servo. Test fit the servo into the servo tray. C/A glue 2. Mount the servo to the tray using the mounting screws provided with your radio sys- tem.
  • Page 15 RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. See pictures below: 1. Draw a center line onto the horizontal stabilizer. Then slide the horizontal into the fuselage. Remove covering Center line 2 Using a modeling knife, cut away the covering from the fuselage for the stabilizer and remove it.

  • Page 16: Elevator Control Horn Installa- Tion

    RENEGADE - Instruction Manual ITEM CODE:BH66 Epoxy glue 6. After the epoxy has fully cured, remove the masking tape or T-pins used to hold the stabilizer in place and carefully inspect the glue joints. Use more epoxy to fill in any gaps that were not filled previously and clean up the excess using a paper towel and rubbing alcohol.
  • Page 17 RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. C/A glue E l e v a t o r pushrod C/A glue...

  • Page 18: Vertical Installation

    RENEGADE - Instruction Manual ITEM CODE:BH66 Bend and cut after Control clasp. C/A glue Elevator servo Elevator C/A glue pushrod 1. Using a modeling knife cut away the covering from the fuselage for the rudder and remove it. VERTICAL INSTALLATION. Rudder servo install as same as method of elevator servo.

  • Page 19: Mounting The Tail Wheel Bracket

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. 2. Slide the rudder into the fuselage as same as picture below.  3. While holding the vertical stabilizer Epoxy glue firmly in place, use a pen and draw a line on each side of the vertical stabilizer where it meets the top of the fuselage.
  • Page 20 RENEGADE - Instruction Manual ITEM CODE:BH66 2. Using a pen, mark the locations of the two mounting screws. Remove the tail wheel bracket and drill 1mm pilot holes at the loca- C/A glue tions marked. Mark point C/A glue Left side Secure Right side...

  • Page 21: Rudder Control Horn Installa- Tion

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. RUDDER CONTROL HORN INSTALLA- TION. Rudder control horn install as same as the way of aileron control horn. Please see pic- tures below. Nilon control clasp. 3mm x 35mm. M3 lock nut Control horn of Rudder. C/A glue Mark point Drill 6mm diameter a hole of the mounting...
  • Page 22 RENEGADE - Instruction Manual ITEM CODE:BH66 Rudder pushrod Elevator servo Elevator Rudder pushrod pushrod Rudder servo Bottom side INSTALLING THE THROTTLE PUSHROD. Install one adjustable metal connector through the third hole out from the center of one servo arm, enlarge the hole in the servo arm using a 2mm drill bit to accommodate the servo connector.

  • Page 23: Installing The Switch

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. Mark point Secure INSTALLING THE SWITCH. 1) Cut out the switch hole using a modeling knife. Use a 2mm drill bit and drill out the two mounting holes through the fuselage side. 2) Secure the switch in place using the two machine screws provided with the radio system.
  • Page 24 RENEGADE - Instruction Manual ITEM CODE:BH66 INSTALLING THE RECEIVER AND BATTERY. 1. Plug the servo leads and the switch lead into the receiver. You may want to plug an aileron extension into the receiver to make plugging in the aileron servo lead easier when you are installing the wing .

  • Page 25: Wing Attachment

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. 3) A drop of C/A glue on the wheel collar screws will help keep them from coming lose during operation. Repeat the process for the other wheel. WING ATTACHMENT. 2) Using the hardware provided, mount See picture wing attach to fuselage.
  • Page 26 RENEGADE - Instruction Manual ITEM CODE:BH66 BALANCING. 1) It is critical that your airplane be bal- anced correctly. Improper balance will cause your plane to lose control and crash. THE CENTER OF GRAVITY IS LOCATED 75mm BACK FROM THE LEADING EDGE OF THE WING.

  • Page 27: Control Throws

    RENEGADE - INSTRUCTION MANUAL ITEM CODE:BH66. CONTROL THROWS. 1. We highly recommend setting up a plane using the control throws listed. 2. The control throws should be meas- ured at the widest point of each control sur- face. 3. Check to be sure the control surfaces move in the correct directions.
