F4U CORSAIR
Glow and EP
ALL BALSA - PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED.
INCLUDING AIR RETRACT.
AIR UP, AIR DOWN, TURN AND TWIST OLEO STRUTS LANDING GEAR.
95% ALMOST READY TO FLY
SPECIFICATION:
- Wingspan: 2,280 mm (89.76 in).
- Length: 1,800 mm (70.87 in).
- Weight: 9.6 - 10kg (21.1 - 22lbs).
- Wing area: 94.6dm2.
- Wing loading: 101.5g/dm2.
- Servo mount: 42mm x 21mm.
- Spinner size: Corsair style (not included).
- Wing type: Naca Airfoils.
- Main gear type: Rotary 90 degree Air retract
gear and CNC suspension metal struts (included).
- Tail gear type: Air retract gear with
CNC suspension metal struts (included).
Instruction Manual Book
Item code: BH64
New improvement
Parts listing required (not included):
- Radio: 6 channels.
- Servo: 09 size (39.9 x 20.1 x 38.1)mm.
Standard high torque servos.
- Engine : 55 - 65 cc gas.
- Motor: Brushless outrunner 5000 - 6500W, 230KV.
- Propeller: Suit with your engine.
Recommended receiver battery (not included):
- Motor: RIMFIRE. 50 cc.
- Lipo cell: 12 cells 5500 - 6000mAh.
- Receiver battery: 6.0V 2400-2600mAh(2 Packs).
- ESC: 120A.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F4U CORSAIR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Horse Model F4U CORSAIR

Summary of Contents for Black Horse Model F4U CORSAIR

  • Page 1 Instruction Manual Book Item code: BH64 F4U CORSAIR New improvement Glow and EP ALL BALSA - PLY WOOD CONSTRUCTION. COVERED IN A HEAT-SHRINK FILM WITH PRINTED. INCLUDING AIR RETRACT. AIR UP, AIR DOWN, TURN AND TWIST OLEO STRUTS LANDING GEAR.

  • Page 2: Table Of Contents

    Thank you for purchasing Black Horse Model products. With over 19 years experience in production and fly testing, Black Horse Model is committed to bring the best quality products and good service to customers. Along with a team of creative engineers and skilled workers, we will always accompany with customers by our great experiences, fully enthusiasm...

  • Page 3: Warranty

    In that Black Horse Model has no control over the final assembly or material used for final assembly, SUGGESTION Black Horse Model is not responsible for loss of use , or other incidental or consequential damages. To avoid scratching your new airplane, do not...

  • Page 4: Covering Tools

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 FLIGHT WARNINGS ADHESIVES AND REQUIRED TOOLS When ready to fly, first extend the transmitter aerial. Thin CA Switch on the transmitter. 30-minute epoxy Switch on the receiver. 6-minute epoxy Check that the wings are correctly fitted to the Threadlocker thread locking cement fuselage.
  • Page 5 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 • Officially designated AMA Air Show Teams (AST) are authorized to use devices and practices as defined within the Team AMA Program Document. (AMA Document #718.) (j) Not operate a turbine-powered aircraft, unless in compliance with the AMA turbine regulations. (AMA Document #510-A.)

  • Page 6: Tools & Supplies Needed

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 PARTS LISTING (NOT INCLUDED). Servo extension leads....pcs. 330mm ..2 pcs. 190mm ..2 pcs. Propeller: Suit with your engine. Engine: 55 - 61..1 pcs. LiPo. 6S - 22.2V 300-5000mAh ..2 Packs Motor: 50cc ...
  • Page 7 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 : Fuselage. : Retract main gear (22a, 22b ). : Wing panel ( 2a, 2b . Door strut gear (23a, 23b ) : Horizontal stabilizer Wood - motor mount. : Rudder. Engine mount.

  • Page 8: Installing The Ailerons And Flaps

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE AILERONS AND FLAPS. 44mm Pinned hinge - - - - - - - - - - - - - 8 67mm Pinned hinge - - - - - - - - - - - - - 12...

  • Page 9: Installing The Ailerons And Flap Servos

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE AILERONS AND FLAPS SERVOS. Place the servo into the servo tray. Center the servo within the tray and drill 1.5mm pilot holes through the block of wood for each of the four mounting screws provided with the servo.
  • Page 10 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Flaps Flaps servos. 2 mm approx.16mm 3x12mm Cap Screw For Flap. 3mm Flat Washer For Flap. 3mm Hex Nut Screw 2x10mm Flap Tp Screw Flap 1.5mm 1.5mm...
  • Page 11 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Aileron Aileron servos. 2 mm approx.16mm 3mm Flat Washer Aileron Aileron 3mm Hex Nut 3x12mm Cap Screw Aileron Aileron 1.5mm Screw Aileron 2x10mm Tp Screw 1.5mm Cut off shaded portion Drill holes using the stated.
  • Page 12 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 2x10mm Bottom view Aileron Aileron Aileron 3x15mm Tp Screw Horn 3x12mm Cap Screw C . A Aileron Aileron C . A Bottom view Flap 3x12mm Flap Flap Cap Screw 3x15mm Horn Tp Screw Cut off shaded portion carefully.

  • Page 13: Installing The Air Retractable Landing Gear

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE AIR RETRACTABLE LANDING GEAR 4x20mm Socket Head 6x65mm Socket Head Door strut gear Cap Screw Cap Screw - - - - - - - 8 - - - - - - 2...
  • Page 14 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 4x20mm Socket Head Cap Screw 4mm Spring W asher 4mm Flat washer Bottom view Mounting gear Bottom view Assemble left and right Drill holes using the stated. Cut off shaded portion sides the same way.
  • Page 15 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 2x10mm Tp Screw Mounting gear 1.5 mm Bottom view Collar 115mm Wheel 6x65mm Socket Head Cap Screw 6mm Flat washer Bottom view Cut off shaded portion carefully. Assemble left and right sides the same way.
  • Page 16 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Cut off shaded portion carefully. Apply instant glue (C.A glue, super glue). C . A Assemble left and right sides the same way. Mounting gear Wheel Well C . A Bottom view Bottom view...
  • Page 17 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Plastic part for wing Gun set for wing Bottom view Bottom view C . A Apply epoxy glue. Apply instant glue Cut off shaded portion (C.A glue, super glue). carefully. C . A...
  • Page 18 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING VALVE CONTROL Valve one way Connector 200mm - - - 1 Valve control Air tank - - - 2 - - - 1 Air line sets - - - 2 2 way conector...
  • Page 19 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 4 WAY CONNECTER TAIL GEAR 2 WAY CONNECTER 4 WAY CONNECTER 2 WAY CONNECTER 2 WAY CONNECTER 4 WAY CONNECTER 2 WAY CONNECTER Air tank Air tank...

  • Page 20: Installing The Engine Mount

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE ENGINE MOUNT May be you also need to trim some wood from the tri-angle Using plate of plywood (supplied with the kit) mark the holes wood for the installation is easy.

  • Page 21: Installing The Engine

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 OPTION 2: INSTALLING THE ENGINE Be sure to equip Not included. INSTALLING THE FUEL TANK. air vent pipe. Tygon tubing (Gas). And silicone tubing (Methanol). The stopper has been pre-assembled at the To carburetor fuel inlet factory.
  • Page 22 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE ENGINE 5x100mm Socket Head 50mm Pushrod wire 5mm Rubber Washer Cap Screw - - - 2 - - - - - - 4 - - 4 12x70mm Aluminum 5mm Flat washer...

  • Page 23: Installing The Fuselage Servos

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE FUSELAGE SERVOS 1) Install the rubber grommets and brass collets into the elevator, rudder and throttle servos. Test fit servos into the servo tray. Trim the tray if necessary fit your servos.

  • Page 24: Mounting The Cowl

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Adjust the throttle input (transmitter throttle 4x4mm stick), throttle trim movement and the 2x10mm carburattor opening to the suitable position Linkage stopper and screw in the 4x4mm set screw. Screw Pushrod wire While holding the cowl firmly in position,...
  • Page 25 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 3x12mm Tp Screw - - - 10 Plastic - - - - - - 5 Cowl area cutout for muffler Cowl area cutout for engine head. 3x12mm Tp Screw plastic Cut off shaded portion Apply epoxy glue.
  • Page 26 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 3x12mm Tp Screw INSTALLING THE ENGINE MOUNT INSTALLING THE ELECTRIC MOTOR (EP VERSION) 12x70mm Aluminum M4 Blind Nut - - - - - 4 10x10mm 10x10mm Aluminum 4 mm Spring Washer - - - - - 4...
  • Page 27 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Fuselage top side 175mm INSTALLING VERTICAL STABILIZER 2.6x935mm Push rod - - 1 3x30mm Socket Head Cap Screw - - - - - 1 3x12mm Cap Screw - - - - - - 2...
  • Page 28 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 BOTTOM VIEW 44mm Pinned Hinge 3x12mm Cap Screw...
  • Page 29 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Fuselage top side 3x12mm Cap scew Flash washer Push rod Ball link Servo tail 3mm Hex nut Rudder servo Rudder...

  • Page 30: Installing Horizontal Stabilizer

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING HORIZONTAL STABILIZER 2.6x1090mm Push rod - - - 4 Ball link - - 2 3mm Flat Washer 3x25mm Socket Head Cap Screw - - - - - 2 - - - - - 2...
  • Page 31 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 BOTTOM VIEW C . A 3x12mm Cap Screw...
  • Page 32 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 C . A 3x12mm Cap scew Flash washer Push rod Ball link Servo tail Fuselage top side 3mm Hex nut...

  • Page 33: Installing The Tail Gear, Rudder

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Elevator servo INSTALLING THE TAIL GEAR, RUDDER 3x8mm Tp Screw 950mm Cable rod - - - - - - - - - - 1 - - - - - - 2 Connector - - - - - - 1...
  • Page 34 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 800mm Air Hose Air Hose Spring 800mm BOTTOM VIEW...
  • Page 35 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 BOTTOM VIEW Cable rod Air Hose Air Hose 4x16mm 4mm Spring Washer 4mm Flat Washer 3x12mm Tp screw 3x8mm...
  • Page 36 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 3x12mm M3 Metal Clevit 3mm Connector Cab rod Hex Nut Fuselage top side...

  • Page 37: Installing The Switch, Receiver And Battery

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE SWITCH, RECEIVER AND BATTERY INSTALLING THE SWITCH 1) Plug the servo leads and the switch lead into the receiver. You may want to plug an aileron extension 1) The switch should be mounted on the fuselage...
  • Page 38 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Open/Close Open/Close Canopy glue Adhesive tape. Apply epoxy glue.

  • Page 39: Installing The Wing To The Fuselage

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 INSTALLING THE WING TO THE FUSELAGE *** Test fit the aluminium tube dihedral brace into each wing haft. The brace should slide in easily. If not, use 220 grit sand around 19x425mm Aluminium tube.

  • Page 40: Installing The Propeller

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Main wing must be inserted and attached completely before fixing with screw. Cap screw for main wing fixture INSTALLING THE PROPELLER Must be purchased separately!
  • Page 41 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 Antenna Antenna Cut off shaded portion carefully.

  • Page 42: Balancing

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 BALANCING LATERAL BALANCE After you have balanced a plane on the C.G. It is critical that your airplane be balanced You should laterally balance it. Doing this will correctly. Improper balance will cause your plane to help the airplane track straighter.

  • Page 43: Control Throws

    INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 In order to obtain the CG specified, reposition Bottom View the receiver and other equipment. If not obtain the CG specified, add a weight and adjust. Do not fly before confirming the correct location of the CG. If the...
  • Page 44 INSTRUCTION MANUAL F4U CORSAIR Item code: BH64 FOR YOUR RADIO INSTALLATION BASIC CONNECTION FOR AIRPLANE AND ADJUSTMENT OF SERVOS Example of connection For more information, refer to radio system instruction manual. Follow instruction manual of Engine and Battery. Aileron Servo...

  • Page 45: Main Gear Dimensional Detail

    MAIN GEAR DIMENSIONAL DETAIL 72mm 60mm 41mm 6.1mm hold TAIL GEAR DIMENSIONAL DETAIL...
  • Page 47 I/C FLYING WARNINGS Always operate in open areas, away from NEVER fly near power lines,aerials or AL WAYS adjust the engine from behind factories, hospitals, schools, buildings other dangerous areas including airports, the propeller, and do not allow any part of and houses etc.
  • Page 48 I/C FLYING GUIDELINES Operate the control sticks on the ALWAYS land the model INTO When ready to fly, first extend transmitter and check that the the wind, this ensures that the the transmitter aerial. control surfaces move freely and in model lands at the slowest possible the CORRECT directions.
