READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: COS52OSB5CR Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. pgs. 4 - 5 Wiring.
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. *The motor stabilization pieces may be dicarded at this time. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) (2.13m) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft.
5. Fan Assembly. If you wish to extend the hanging length of your fan, you must remove the hanging ball from the downrod provided to use with an extended set screw hole set screw downrod (sold separately). [If you wish to use the downrod provided, please proceed to instructions stop pin following the dotted line below.]...
5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.
7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. hanging bracket Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and push up.
9. Light Kit Assembly (Optional). motor housing Remove 1 screw from motor plate on underside of motor housing and partially loosen the other 2 screws. Align slotted holes in center of fitter plate with loosened screws in motor plate, allowing molex connections from motor housing to come through hole in middle of fitter plate.
10. Automated Learning Process./Activating Code. CAUTION: The remote control transmitter can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. TRANSMITTER (back) switches This remote control transmitter is equipped with 16 code combinations to prevent possible interference from or to other remote units such as garage door openers, car alarms or security...
11. Remote Control Operation. HI button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed OFF button - turns fan OFF button - controls LIGHT function; turns light ON/OFF when tapped quickly.
Service at 1-800-527-1292 to arrange for return of fan. direction. 3. Verify that receiver is wired properly. Return fan, shipping prepaid, to Litex Industries, Ltd. We will 4. Check to be sure fan is wired properly. repair or ship you a replacement fan, and we will pay the 5.
