TuffStuff Apollo Standard Assembly Instructions Manual page 7

CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
ITEM NO. DESCRIPTION
17 INSERT TUBE 1 X 16
26 CABLE RETAINER BRACKET(L-SHAPED)
45 ADJUSTABLE PULLEY BRACKET
59 TOP UPRIGHT CONNECTOR
60 TOP PLATE DOUBLE PULLEY BRACKET
61 SINGLE COLUMN UPRIGHT
62 SINGLE COLUMN CABLE
63 LOW ROW STABILIZER
64 LOW ROW FOOT SUPPORT
65 HIGH/LOW DOUBLE PULLEY BKT (SOLID SHANK)
66 HIGH/LOW DOUBLE PULLEY BKT (HOLLOW SHANK)
67 SINGLE COLUMN CARRIAGE
68 SINGLE COLUMN HANDLES
69 BOTTOM UPRIGHT CONNECTOR
76 ALUMINUM CAP 1" RD. (CAP-100)
78 ALUMINUM PULLEY 3/8" X 4 1/2"
81 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8
83 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1
86 COIL CHAIN Z/P 3/16 X 21
89 FINISHED HEX NUT B/O 1/2-13
94 FLAT WASHER SAE 3/8"
97 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4
98 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1
101 HEX HEAD CAP SCREW 3/8-16 X 1 3/4
105 HEX HEAD CAP SCREW 3/8-16 X 3 1/4
106 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/2
107 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 3/4
108 URETHANE BUMPER 962
110 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 3/4
113 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3
116 LEATHER ANKLE STRAP
ITEM NO. DESCRIPTION
78 NYLON PULLEY 3/8 X 4 1/2
Single Column Station
Single Column Station (Deluxe)
Single Column Station (Standard)
All parts same as Single Column Station (Deluxe), except for the parts listed below
Parts List
PART NO. QTY. ITEM NO.
UP0053 1 118 NYLON BALL 1 3/4 X 1/4
UP0014 6 121 NYLON D HANDLE (# H834A)
UP0127 1 123 NYLON INSERT JAM LOCK NUT 3/8-16
UP2003 1 125 NYLON INSERT LOCK NUT 3/8-16
UP1746 1 126 NYLON INSERT LOCK NUT B/O 5/16-18
UP2013 1 128 ALUMINUM PULLEY PULLEY 3/8 X 3 1/2
UP2023 1 129 NYLON SPACER 3/8 X 3/4 X 3/8
UP0669 1 130 NYLON STEM BUTTON 12.5 mm X 26 mm x 9.5 mm
UP0670 1 138 PLASTIC INSERT CAP 1" RD. 10-12 GA.
UP1022 1 139 WASHER 3/8 X 1 1/2 CHROME
UP1023 1 142 PLASTIC INSERT CAP 2" SQ. 10-14 GA.
UP0999 1 143 PLASTIC TUBE END 1 X 1 1/4 X 3/8
UP2005 1 146 PULL PIN 1/2 X 2 7/8 (YELLOW KNOB)
UP2004 1 150 RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042
BNH0537 2 154 RUBBER CORR MAT 1/8" X 1 1/2 X 5
BNH0069 6 156 RUBBER GRIP 1 ID X .125 X 8
BNH0527 4 160 RUBBER GRIP 1/2 X 4
BNH0115 1 163 SAFETY TAPE ANTI-SLIP 4" X 7 3/4
BNH1262 1 166 SHOULDER BOLT ALLOY 3/8 X 3/4
BNH0201 3 167 SNAP LINK Z/P 8MM X 80MM
BNH0239 35 169 SOCKET SET SCREW ALLOY 10-32 X 1/8
BNH0283 2 170 SOCKET SET SCREW ALLOY 3/8-16 X 1/2
BNH0275 1 174 SPLIT LOCK WASHER 3/8"
BNH0274 5 176 SPLIT LOCK WASHER Z/P 1/2"
BNH0312 5 178 STRAP BRACKET 20 #SF20 STAINLESS STEEL
BNH0280 2 184 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1-1/2
BNH0281 1 186 DECAL-ADJUST CABLE HERE
BNH0244 2 191 DECAL-WARNING KEEP HANDS AND FINGERS...
BNH0318 1 195 PLASTIC TIES 14 1/2"
BNH0282 2 196 DECAL-EXERCISE SINGLE COLUMN STATION
BNH1231 1
Parts List
PART NO. QTY. ITEM NO.
BNH0506 6 128 NYLON PULLEY 3/8 X 3 1/2
DESCRIPTION
DESCRIPTION
PART NO. QTY.
BNH0047 2
BNH1215 2
BNH0365 10
BNH0214 6
BNH0215 2
BNH1266 5
BNH0392 2
BNH0547 8
BNH0002 4
BNH1015 1
BNH0012 1
BNH1089 1
BNH0641 2
BNH0419 1
BNH1226 1
BNH0966 2
BNH0530 1
BNH1227 4
BNH0718 2
BNH0065 3
BNH0473 4
BNH0474 1
BNH0658 4
BNH0572 3
BNH0652 2
BNH0142 2
BNH0789 1
BNH0620 1
BNH0703 2
BNH1676 1
PART NO. QTY.
BNH0553 5
8
