Gateway Assigned with a Public IP Address and Serving as an Internet Sharing Device
The SmartVoice gateway will have a Public IP address, regardless of whether it is the public IP from a
static setting, DHCP (using a Cable Modem), or PPPoE (to connect to your ADSL account), and can use
the built-in Internet sharing functions to allow other PCs attached to SmartVoice gateway LAN ports to
share the Internet connection. The network connection is shown in following diagram.
Gateway IP Settings
NAT/STUN Settings
DDNS Settings
DHCP service for PCs, please refer to page
24 for the gateway DHCP server settings
Note:
The above diagram shows a 4-port SmartVoice gateway for illustration purposes.
An 8, 16 or 32 port SmartVoice gateway could also be used depending upon your
network requirements.
SmartVoice Gateway(s) User Guide
YML832 Rev1
Needs to be set up as either in static IP, DHCP, or PPPoE
Unnecessary (Disabled)
Unnecessary (Disabled)
Default private IP addresses of the gateway LAN ranging
from: 192.168.8.1-192.168.8.253
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.8.254
PC can be set either in DHCP or static IP mode
15
