3.1.2 SYS MENU Settings

While in the STOP mode, press MENU
Using the arrows,
SYS MENU (Figure 3-2). The following items can be set in the SYS MENU (Table 3-2).
Settings Setting Details
ID ID number setting
DATETIME Date and time setting
OSD DISP Display/do not display superimposed information
Display/hide the superimposed information by
OSD MODE
the camera mode
OSD TIME Trigger clock setting
CAFM DIS Display/do not display mark for center of image
FRM DISP Frame counter display setting
FRM TIME Frame time standard setting
REL TIME Flame relative time display setting
TIMSTAMP Time stamp recording setting
EXP TIME Exposture timing setting
SYNC TIME Synchronized time setting
SYNC SEL Synchronized signal setting
The synchronized signal setting at the time of
EST VIEW
EST VIEW
VIDEOOUT Display/do not display image
ZOOM Zoom playback image
SCROOL Scroll playback image
BEEP Remote control operation sound ON/OFF
AUTOVIEW Automatic switch to VIEW mode
WARNING Display/do not display warnings
TRIG SET External trigger setting, recording method setting
SIG SET External input/output signal polarity setting
SYS SET Segment memory setting, reboot
INFO System information display (cannot be set)
After setting in the SYS MENU, press STOP
mode). Also, select "TOP MENU > SYS MEN" at the top of the SYS MENU and press SET
the TOP MENU.
(00235)
to switch from the status screen to the TOP MENU.
select "SYS MENU from the TOP MENU and press SET
Figure 3-2 SYS MENU
Table 3-2 SYS MENU Settings
or MENU
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
Refer to Chapter 5 "System Settings"
to return to the status screen (STOP
3-3
to display the
to return to
