Note 6) Since a frame size setting and the fluctuation of the black level by a temperatures are
large when using the high-speed shutter for 1 to 5 microseconds, I recommend
maintaining and photoing black balance strongly.
Custom Shutter Exposure Times
３）
1~9996 microseconds, 1 or 2 microsecond increments
Photographic
Speed (pps)
100 or less
250
500
1,000
1,500
2,000
3,000
4,000
5,000
6,000
7,000
8,000
10,000
15,000
20,000
30,000
40,000
50,000
60,000
80,000
100,000
150,000
198,000
Note 1) The exposure times that can be set with the custom shutter are automatically calculated
by the firmware.
7.1.6 Automatic Exposure
With the automatic exposure function ON, the shutter exposure time can be automatically adjusted
from the shortest exposure time (10usec) to the longest exposure time (designated by the shutter
exposure time).
7.1.7 DRES Mode (Dynamic Range Extender)
The brightness is determined in pixel units and only the pixels above a given level are exposed by the
shutter speed determined in the DRES mode. Pixels below the given level are exposed by the normal
shutter speed.
It is possible to take extended dynamic range images by suppressing the saturation of the areas with
high luminance.
Possible Settings and Intervals for Exposure Times
Pixels (HxV)
Maximum
1280x1024
1280x1024
1280x1024
1280x1024
1280x1024
1024x1024
800x800
704x704
624x624
640x480
512x512
512x384
452x368
436x192
320x192
192x144
144x144
128x128
96x96
64x64
64x32
16x64
4x16
7-4
Setting (us)
Minimum
9994 1
3995 1
1995 1
995 1
662 1
494 1
329 1
246 1
196 1
163 1
139 1
122 1
97 1
64 1
48 1
31 1
22 1
18 1
14 1
10 1
8 1
4 1
3 1
Setting (us)
1 2
or
1 2
or
1 2
or
1 2
or
1 2
or
1 2
or
1 2
or
1 2
or
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
