5 Dimensional drawing & centre of gravity
5 - 1 Dimensional drawing
RYN50-60 E
Drain outlet
(I.D. J 15.9 hose for connection)
4 x holes for anchor bolts (M8 or
M10)
• Outdoor Units • R-410A • RYN-E3V1B
Name plate
Brand name label
• Split Sky Air • Outdoor Units
Minimum space for air passage
In case of removing stop valve
cover
Terminal strip with earth
Wiring inlet
terminal
Liquid stop valve
(J 6.4 CuT)
Gas stop valve
Service port
(J 12.7 CuT)
unit (mm)
Wall height on air outlet side =
less than 1200
Outdoor air temperature
thermistor
3D051657D
3
1
5
10
