Introduction

The new FuntanaX 100 .90 3D ARF was designed exclusively for Hangar 9
Sebastiano Silvestri. He based the FuntanaX 100 on his highly successful KatanaS TOC design.
The FuntanaX 100 can do it all—harriers, torque rolls, blenders, and almost anything else you can dream up. It's all
possible, thanks to an extremely lightweight, all-wood airframe and big control surfaces that give the FuntanaX 100 a
very impressive thrust-to-weight ratio and crisp control authority at any airspeed. Sebastiano's signature UltraCote
scheme and factory-painted parts such as the cowl and wheel pants complement the performance perfectly.

Contents of Kit

J
C
F
B
G
D

Radio and Engine Requirements

• 6-channel radio system (minimum)
• 5 high-torque servos (see Servo Selection section)
Recommended JR Systems
• PCM10X
• XP8103
• X-378
• XP662
• XF631
Recommended Engines
• .61 2-stroke
• 1.00 4-stroke
E
A
E
C
H
I
Saito 1.00 FA-AAC
SAIE100
by Italy's most famous aerobatic pilot,
®
Large Parts:
A. Fuselage w/Hatch
B. Fuselage Hatch
C. Wing Set w/Ailerons
D. Carbon Fiber Wing Tube
E. Tail Set
F. Canopy
G. Fiberglass Painted Cowl
H. Fiberglass Painted Whl Pnts HAN4184
I. Carbon Fiber Landing Gear HAN4185
J. Side Force Generators
Items Not Shown:
Fuel Tank (Assembled)
Engine Mount
2 3 / " Wheels
4
Carbon Fiber Tail Support
Hardware Pack
Decal Set
Evolution .61NT
EVOE0610
JR XP6102
trim
®
HAN4176
HAN4177
HAN4178
HAN4179
HAN4180
HAN4182
HAN4183
HAN4188
HAN1987
HAN90M
HAN305
HAN4181
HAN4186
HAN4187
JR XP9303
3
