CALLING
UP
AND
STEPPING
THROUGH PROGRAM
SEQUENCES
To
get into the
PROGRAM
SEQUENCE
MODE
hit
PREFIX
letter
D, followed by any
number
from
to
9,
followed
by
ENTER.
This
gets
you
to
one
of the 10
PROGRAM
SEQUENCES.
What
will
appear
in
the
Alphanumeric
Display looks
like this:
ki>****1
SYSTEM CONTROLLER
17
PRDC5RAM
B PI 2e
QH
HEI
EIHHE]
RECORD
INTERLOCK
G^
The number
in
the
PROGRAM
DISPLAY
is
the
first
program
of the
PROGRAM
SEQUENCE.
The B
at the
left
of
the screen indicates the beginning of the
SEQUENCE.
As you
step
through
the
SEQUENCE,
the
number
that
appears
in
this
spot
indicates the previous
program number. The
center of the display
shows
the
PROGRAM
SEQUENCE
number, and
the
number
to the
right
of the screen
is
the
program
number
next
in line
in
the
SEQUENCE.
To
step
through
the
PROGRAM
SEQUENCE,
use the
A
PREFIX
switch to
go forward and
the
B
PREFIX
switch
to
go backward.
You
can
also
use
PROGRAM ADVANCE
and
PROGRAM
BACKSTEP
footswitches
for these functions. (Note
that the footswitches
aren*t supplied with the instrument.)
Experimenting
with the programs,
editing
them, and
stepping through
the
PROGRAM
SEQUENCES
should keep you
busy
for
at least
a
few
minutes.
It
should
also start generating questions
about
other
features
on
the instrument. Section
1
1
of the manual
provides
brief descriptions of
all
the various functions
of the
Memorymoog,
while Section
III
offers step-by-step
explanations.
From
this point,
refer
to those
sections as the
need
arises.
/"
