Moog MEMORYMOOG 345 Owner's And Service Manual page 10

1.7
KB MODE.
KEYBOARD MODE
affects
the
priority
of
the
keyboard
when
it*s in
both
mono
and polyphonic
modes.
In
mono
mode,
the
SYSTEM CONTROL-
LER
(3.0)
Alphanumeric
Display
shows
either
**MONO
1,
2
or 3/* depending on
the
mono mode
programmed.
Mono
1 is
last-note priority,
Mono
2
is
low-note
priority,
and
Mono
3
is
high-note
priority. In
polyphonic mode,
the
Alphanumeric
Display
will
show
either
"POLY
1
" (cyclic),
"2** (cyclic
with
memory), *3"
(reset
to voice A),
or
"4'* (reset
to voice
A
with memory).
Voltages
routed to an external synth
via the
EXTERNAL
SYNTHESIZER OUTPUT
(14.0)
are affected
by
this control.
1.8
HOLD.
Lets
you
build
up chords and
transpose
them
in
parallel
motion from
the
keyboard. Holding
a
chord and then
pressing the
HOLD
button
will
memorize
the chord. Holding
down
the
HOLD
button and then
pressing notes on
the
keyboard
will let
you
build widely spaced chords. Re-
leasing the
HOLD
button memorizes
the chord.
The chord can
then be transposed from
the
last
note
you
played on the keyboard.
1.9ARPEGGIAT0R.
Continuously
triggers
note played on
the key-
board. Rate
is
set
by
the
LFO
(5.0)
speed.
The
Clock can be overridden by
an
external
trigger
source
at the
CLOCK
IN
(15.5)
on
the
back
panel.
The
internal
clock
is
reset
by
the key-
board
so
you
can always
play
in
time.
The
Arpeggiator operates
in six
different modes:
1)
Plays back
notes
from bottom
to top,
unlatched
(notes stop
when you
lift
off the
keyboard).
2)
Plays back
notes
from
top to bottom,
unlatched.
3)
Plays back notes from
top to
bottom, and
then from bottom
to top, unlatched.
4)
Plays
back
notes
from bottom
to top
(latched).
The
notes
will
continue
if
you
lift
your hands
off the keyboard.
5)
Plays
back
notes
from
top
to
bottom,
latched.
6)
Plays
back
notes
from
top
to
bottom,
and then from bottom
to top, latched.
•
D
AUTO TUNE
<^i^*
''/\"
TUNE
• •
•
DDD
MONO
MULTIPLE KB OUT
5
TRIGGER
D
10 GLIDE ON/OFF
GLIDE
• • •
DDD
KB
MODE
HOLD ARPEGGIATOR
^\l//
^\l//
^/ \^
^/ \^
10
10
PITCH BEND MODULATION
AMOUNT
AMOUNT
O/
1.10
PITCH
BEND AMOUNT.
Lets
you
vary the
maximum
range of the
PITCH
BENDING WHEEL
(2.2)
up
to
±
1
octave.
Note
that
this
control
is
programmable.
1.11
MODULATION AMOUNT.
Sets a
programmable
initial
modulation amount.
The
MODULATION WHEEL
(2.3)
adds
to the
amount
set
by
this
control.
o
•
D
AUTO TUNE
TUNE
• • •
DDD
MONO
MULTIPLE KB OUT
5
TRIGGER
•
D
10 GLIDE ON/OFF
GLIDE
#
• •
DDD
KB
MODE
HOLD ARPEGGIATOR
1
^\l//
-v\l//
2
i
2
—8
</ \^
^/ \"-
10
10
1
PITCH BEND MODULATION
1
^
AMOUNT
AMOUNT
J
o
