3.3
NUMERIC KEYBOARD.
This calculator-type keyboard
is
used
for
calling
up programs and
other
control functions.
You
do
this
by
hitting
one
or
two numbers
(from
to
99)
and
then
pressing
the
ENTER
button.
3.4
RECORD
INTERLOCK.
This switch
is
used to temporarily lock the front panel
settings
in
memory.
By
hitting
LOCK,
the
Alphanumeric
Display
(3.2)
will
read
*TOCK/'
indicating that the current panel
settings are
temporarily
locked,
and
turning pots or
hitting switches
will
have
no
effect.
This allows you
to
call
up
another patch from
memory
(by
hitting a
number
and
pressing
ENTER)
without
losing the locked patch.
Hitting the
LOCK
switch
after
youVe
called
up another patch
will
bring
up
the locked patch. This
is
useful for
checking
edited patches against the
original version.
3.5
STORING A PATCH
IN
MEMORY.
This
is
done by
holding the
LOCK
button
(3.4)
down
and
hitting the
ENTER
button
(see 3.3).
This loads
whatever
is
currently
shown
on
the
front panel
into the
memory
position
called
up
in
the
Program
Display
(3.1
).
Note
that recording
a
patch
is
impossible
if
the
Memorymoog
is
*Vrite
disabled,''
meaning
that a protect function
against storing
unwanted
information
in
memory
is
on.
To
turn the protect function
off
and
on,
you must know
the
four-digit security
code
(see
Section
III).
Attempting
to store a patch
in
memory
when
the disable feature
is
on
will
cause the
Alphanumeric
Display
(3.2)
to read
'^DISABLED.''
When
a patch has been
successfully written into a
memory
position
the Alphanumeric
Display
will
read
**RECORDED.*'
3.6
PREFIX BUTTONS.
PREFIX
A
advances programs
stored
in
the
PROGRAM
SEQUENCE
MODE
(see
below). Also advances program
number
by one
in
normal
operating mode.
PREFIX
B
steps
in
reverse
through
the
programs
in
the
PROGRAM
SEQUENCE MODE
(see
below). Backsteps program number
by one
in
normal
operating
mode.
PREFIX
CI
(hit
Q
hit
7,
hit
ENTER)
saves
programs onto
cassette
tape
(for
more
information on
this
procedure
see the next section of the
manual).
PREFIX
C2
(hit C, hit
2,
hit
ENTER)
loads programs from
cassette
tape
into
the
Memorymoog's memory.
PREFIX C3
(hit C, hit
3,
hit
ENTER)
verifies
correct loading of programs
when
putting
programs from
the
Memorymoog
onto
cassette tape.
PREFIX C4
is
used for defeating voices
that aren't
tuning up
for
what-
ever reason. See
text
in
next section of the manual
for
details.
