  • Page 1 BMR 80 English Domestic hot water calorifier for wall-hung boilers 29/05/06 Installation instructions Instructions for use Technical instructions...
  • Page 2: Table Of Contents

    Attention must be paid to the warnings on safety of persons and equipment. Specific information Information must be kept in mind to maintain comfort. Reference Refer to another manual or other pages in this instruction manual. BMR 80 29/05/06 - 300008885-001-A...
  • Page 3: Introduction

    Introduction BMR 80 domestic hot water calorifiers are connected to the side of For a proper operating of the boiler, follow carefully the wall-hung boilers. instructions. 1 Compliance Compliance of design and manufacture Electrical compliance / Marking This product complies with the requirements of European Directive This product complies to the requirements to the European Directives 97 / 23 / EC, Article 3, Paragraph 3, on pressure equipment.
  • Page 4: Main Dimensions

    10 Domestic hot water outlet R 3/4 11 Domestic cold water inlet R 3/4 12 Heat exchanger inlet G 3/4 13 Heat exchanger outlet G 3/4 R: Conical thread G: Exterior cylinder thread, sealed by flat joint BMR 80 29/05/06 - 300008885-001-A...
  • Page 5: Technical Characteristics

    2 Technical characteristics BMR 80 Primary circuit (heating water) Maximum operating temperature °C Maximum operating pressure Maximum operating pressure in accordance with W/TPW (3) Coil water capacity Coil exchange surface 0.75 Secondary circuit (domestic water) Maximum operating temperature °C Maximum operating pressure...
  • Page 6: Installation

    Installation BMR 80 domestic hot water calorifiers are connected to the side of wall-hung boilers. 1 Implementation The DHW calorifier can be placed to the left or right of the boiler. The appliance must be fixed to a solid wall, capable of supporting its weight when full of water.
  • Page 7: Assembling The Boiler/Dhw Calorifier Unit

    2 Assembling the boiler/DHW calorifier unit Fitting the boiler mounting frame with BMR 80 calorifier See: Boiler installation instructions. Fitting the calorifier mounting rail 29/05/06 -300008885-001-A BMR 80...
  • Page 8 Hanging the boiler Hanging the tank BMR 80 29/05/06 - 300008885-001-A...
  • Page 9: Connecting The Calorifier To The Primary Circuit (Exchanger)

    DHW tank. Provision for Switzerland Make the connections according to the instructions of the Société Suisse de l'Industrie du Gaz et des Eaux. Comply with local instructions from water distribution plants. 29/05/06 -300008885-001-A BMR 80...
  • Page 10 Bleed circuit During the heating process, water can flow through the bleed circuit to guarantee the safety of the installation. Do not block! BMR 80 29/05/06 - 300008885-001-A...
  • Page 11: Filling The System

    A connecting part, a T-piece and an annealed copper pipe are provided with the mounting frame. Cut the copper pipe to the correct length using a pipe cutter. A Domestic cold water inlet B to the safety control unit 29/05/06 -300008885-001-A BMR 80...
  • Page 12: Electrical Connection

    - Degas the tank exchanger circuit using the bleed valve provided for this purpose - Check the safety devices (particularly the valve or safety unit), referring to the instructions provided with these components BMR 80 29/05/06 - 300008885-001-A...
  • Page 13: Maintenance

    In hard water regions, it is advisable to ask the fitter to descale the DHW tank exchanger once a year in order to maintain its level of performance. 4 Cladding The cladding of the DHW tank can be cleaned with soapy water. 29/05/06 -300008885-001-A BMR 80...
  • Page 14 Approximately 6 Nm is obtained by manipulating the box spanner with the small lever and 15 Nm by manipulating it with the large lever. 10. After reassembly, check the watertightness of the lateral flange. 11. Switch on. BMR 80 29/05/06 - 300008885-001-A...
  • Page 15: Maintenance Form

    Maintenance form Date Checks made Comments Signature 29/05/06 -300008885-001-A BMR 80...
  • Page 16: Spare Parts

    Spare parts BMR 80 29/05/06 - 300008885-002-A To order a spare part, quote the reference number next to the part required. DE DIETRICH THERMIQUE S.A.S. - Spare parts centre 4, rue d’Oberbronn - F-67110 REICHSHOFFEN - Tél. : (+33) 03 88 80 26 50 - Fax : (+33) 03 88 80 26 98...
  • Page 17 Reference Description 100005562 Tank BMR 80 - Package EE 53 89535525 Complete buffer tank Complete Anode diameter 33 - Length 89538509 89705511 Seal kit 7 mm + retainer ring 5 mm 95014035 Seal ø 25x8-5x2 94974525 Nylon brace 8 mm...
  • Page 18 Sub-assemblies such as motors, pumps, electric valves etc. are guaranteed only if they have never been dismantled. BMR 80 29/05/06 - 300008885-001-A...
  • Page 19: Warranty Certificate

    Warranty certificate Date of purchase: ................Retailer's stamp: Name and address of the purchaser: ....................................................................................................................Tel.:....................Information on the appliance (to be found on the rating plate): Model: ....................Serial number: .................. 29/05/06 -300008885-001-A BMR 80...
