Thank you for buying HeliArtist Products.600 scale fuselage is designed as an easy way to assembly. Please read this instruction manual carefully before assembling the model,and follow all precautions and recommendations in the manual .Make sure to retain the manual for future reference,routine maintenance,and tuning .This scale fuselage is designed for T-REX 600E/Nitro Helicopter series.You can easily put it on your... - Page 3 600scale fuselage,suitable for T-REX600 ESP Helicopter series BEFORE ASSEMBLING TOOL 1:Cutter knife. 2:Hexagon screw 1:Check for all the parts in the list come with the manual. driver 2:Some basic tools are needed to help the assembly. 3:Phillips screw driver. 4:File. 5:Diagonal cutting pliers.
- Page 4 Stick Landing Gear with body and Insert the skid pipes into the cut the protrudent part as the front and rear landing skids as picture.(Hex Cap Screw3x22mmx4) illustration. Stick the Plastic Spacer under the Stick the film in the body. body .(Head:100x18x6mm Plastic Spacer Tail:100x18x12mm Plastic Spacer Hex Cap Screw:3x22mm...
- Page 5 Install the Transition Tail Boom Install the Transition Tail Gearbox and the Transition tail gearbox. and the Transition Tail Boom. When installed all of the parts, Remove the parts like the picture in Adjusted each Servo midpoint, and order to facilitate Installation. the rod length.
- Page 6 Stick the Transition Tail Gear Insert the Transition Tail Gear Box Box with tail (use ¢3.0x12mm into the tail. screw ¢3.0x12mm) When installed the Transition Put the parts from picture Tail Gear Box, whirligig the number 6 into the tail. tail for 90'.
- Page 7 Install the Tail Rotor Arm Adjustment the rack and the Scorpion Tail Gear Box like body. the picture. Install the Tail Cover with Hex Stick the rack on the body with Cap Screw¢2.0x6mm. Combination self-Tapping Screw ¢3.0x16mm x4pcs. Glue the Doll on the seat. Glue the seat's parts like the picture.
- Page 8 Glue the seat on the head. Put the front Mechanical connect with body. Stick Horizontal Stabilizer with Hex Glue the Horizontal Stabilizer with ¢2x6mm Cap Screw the tail. Stick the tail bear rod under the Stick the Decorative Parts Like the picture. tail.
