E - 8
9. Turn on the monitor and the computer.
NOTE: If the settings and connections were made properly, the
LED on the front of the LCD
displays an amber color, the monitor is not receiving the
appropriate input. Please make certain that the above settings
were made properly. If the LED continues to display an amber
color or the monitor is not displaying a stable image, please
refer to the Troubleshooting section of this manual.
10. This completes the installation.
Controls

Front Controls

Brightness: Adjusts the overall image and background screen
brightness.
LED Power Indicator Light: Indicates the monitor's power mode.
Each mode reduces the amount of power used by the monitor:
Mode
ON
Standby & Suspend
Power Switch OFF

Side Control

Power Switch: Turns the power on or off. When the power is on, the
LED is lit.
will show green. If the LED
300
LED Indicator
Green
Amber
No Light
Power Consumption
Typical: 40 watts
Typical: Less than 8 watts
No Power Used
Controls
