E - 10

Specifications

Display:
Compatibility:
Synchronization
Frequencies VGA:
Synchronization
Frequencies High
Resolution:
H Sync Jitter:
Resolution:
Active Display
Area:
Viewing Angles:
13-inch (32.9 cm viewable image size); active matrix;
thin film transistor (TFT); liquid crystal display
(LCD); 0.201 mm dot pitch; RGB vertical stripe color
filter arrangement; 200 cd/m² white luminance, typical;
150:1 contrast ratio, typical
720 x 400: VGA text
640 x 480: VGA, 60 Hz or VESA 72 Hz vertical
refresh
1280 x 1024 non-interlaced: under 72 Hz vertical
refresh
Horizontal:
Vertical:
Pixel Frequency:
Horizontal:
Vertical:
Pixel Frequency:
Less than 5% of pixel frequency (recommended)
Horizontal:
Vertical:
Horizontal:
Vertical:
Up/Down
Right/Left
Specifications
31.0 kHz to 38.0 kHz
55.0 Hz to 73.5 Hz
25.175 MHz, 31.500 MHz
59.0 kHz to 78.125 kHz
55.0 Hz to 76.0 Hz
96 MHz to 126 MHz
1280 dots
1024 lines
257.3 mm
205.8 mm
20°
30°
