  • Page 1 Cód. 50121552 Audio and Video door entry system (One or several accesses doors / General door panel) Plus Nexa Instructions manual T631/PLUS ML rev.0112...
  • Page 2: Table Of Contents

    Each time the power supply is restarted, or after a modification, the system will remain blocked during 30 seconds. Always use RG-59 B/U MIL C-17 or RG-11 coaxial cables, (see page 138). Never use coaxial antenna cable. In installations no longers than 100m., Golmar RAP-5130 cable can be used.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Install or modify the equipment without the power connected. The installation and handling of these equipments must be performed by authorised personnel. The entire installation must be at least 40 cm. away from any other installation. With power supply: Do not use excessive force when tightening the connector screws.
  • Page 4: System Characteristics

    SYSTEM CHARACTERISTICS Coming from previous page Allows one of these functions at once, Configuration with dip switch Sw1 (see page 133): "Autoswitch-on" function. Output for auxiliary relay activation (18Vdc/0,5 A maximum). Call to a slave porter's exchange. Intercommunication function with other monitor or telephone of the same apartment. With Platea Plus / Tekna Plus monitors, addition to the T-940 Plus telephones features: "Autoswitch-on"...
  • Page 5: Door Panel Description

    DOOR PANEL DESCRIPTION oor panel description. General detail of parts, for assembly the door panel. Electronic Embedding boxes Frame modules Aluminium modules modules Door panel description. Main module Push buttons module Sound module EL631 Plus , on video systems with color camera. EL640 Plus , on audio systems.
  • Page 6: Modules Description

    MODULES DESCRIPTION ound module description. Front side. Color camera (only EL631 Plus sound module). Speaker. Door panel audio adjustment. Monitor audio adjustment. Microphone. Sound module push buttons (x2). Back side. Function connector Cn5. Configuration dip switch SW1. Push buttons connector CN9. Configuration dip switch SW2.
  • Page 7: Push Buttons Module El610D

    MODULES DESCRIPTION ush buttons electronic module EL610D description. Front side. Push buttons module (x10). Back side. Input/Output push buttons connector (x3). Configuration dip switch (Push buttons call code). Push button number.
  • Page 8: Embedding Box Positioning

    DOOR PANEL INSTALLATION mbedding box positioning. 1850 1650 1450 The upper part of the door panel should be placed at 1,65m. height roughly. The hole dimensions will depend on the type of door panel. Door panel 90CS CEV90 Model CEA90C CEV90C 99 mm.
  • Page 9: Assembly Electronic Modules

    DOOR PANEL INSTALLATION lace the embedding box. Pass the wiring through the hole made in the bottom part of the embedding box. Level and flush the embedding box. Once the embedding box is placed, remove the protective labels from the attaching door panel holes. ssembly the electronic modules.
  • Page 10: Hold The Frame

    DOOR PANEL INSTALLATION old the frame on the embedding box. Insert the hinge that it is supplied with the product in the embedding box, as shown in the drawing. To hold the frame on the embedding box, insert the hinge in the housings arranged for this purpose in the frame, as shown in the drawing.
  • Page 11: Push Buttons Coding

    DOOR PANEL INSTALLATION lug the push buttons with the connection cable RAP-610D. Use the connection cable RAP-610D, for the connection of the push buttons between the sound module and the push buttons module EL610D and between push buttons modules EL610D, when the distance between modules to connecting is greater due to the composition of the door panels.
  • Page 12: Sound Module Configuration

    DOOR PANEL INSTALLATION escription of the SW1 configuration dip-switch of the sound module. The SW1 configuration dip-switch is located at the upper right side of the back of the module. For dip switch settings, use the tool that is supplied with the sound module.
  • Page 13 DOOR PANEL INSTALLATION escription of the SW2 configuration dip-switch of the sound module. The SW2 configuration dip-switch is located at the upper left side of the back of the module. For dip switch settings, use the tool that is supplied with the sound module.
  • Page 14: Door Panel

    GENERAL DOOR PANEL INSTALLATION eneral door panel (programming modes). Configure the EL631/Plus module of the general door panel in EL501 mode, (see page 115). The general door panel permits the following programming modes: Programming the push button (by call of monitor). Programming the push button (with a backbone code).
  • Page 15 GENERAL DOOR PANEL INSTALLATION Programming the push button ( with a backbone code This programming mode allows to assign a backbone code to push button of the general door panel. Locate the SW2 configuration dip switch of the general door panel to program, placed at the upper left side (back) of the sound module.
  • Page 16: Function Connector Cn5 Description

    GENERAL DOOR PANEL INSTALLATION rogramming the monitors and telephones from a general door panel. Programming the monitor/telephone: This programming mode allows to assign to a monitor / telephone a push button of the general door panel that it wishes to call. Before the push button of the general door panel must be programmed with backbone and monitor/telephone code, (see page 118).
  • Page 17: Final Adjustments

    DOOR PANEL INSTALLATION inal adjustments. If after starting the system it 's considered that the audio volume isn 't correct, proceed with the necessary adjustments as shown in the drawing . The telecamera has a pan and tilt mechanism built in to adjust the telecamera position.
  • Page 18: Door Panel Assembly

    DOOR PANEL INSTALLATION oor panel assembly. In assemblies of a single door panel, it is ready from factory to be mounted. If the door panel to installing is of more than one module it will be necessary make some adjustments to join a door panel with other one.
  • Page 19: Power Supply Installation

    POWER SUPPLY INSTALLATION nstalling the FA-PLUS and FA-PLUS/C power supplies. Install the power supply in a dry and protected place without risk of drip or water projections. To avoid an electrical shock, neither remove the primary protection cover nor handle the connected wire in the terminals.
  • Page 20: Description

    MONITOR DESCRIPTION escription of the Platea Plus / Tekna Plus monitor. PLATEA-PLUS CODE 1 1 7 5 8 8 0 2 10060045 VERSION Nº SERIE 5.00 100615137263 CODIGO / CODE INTER SLAVE MASTER ATENCIÓN Alta tensión. No abrir la tapa. ESCALERA PISO PUERTA...
  • Page 21: Function Push Buttons

    MONITOR DESCRIPTION unction push buttons. On-Off push button. After any monitor reset and during the next 45 seconds, all the monitor functions will be disabled, with the exception of call reception. If the handset is on the craddle allows the activation of an optional second camera (*). If not, allows to make an intercom call or to activate the second camera (*).
  • Page 22: El562 Module

    MONITOR ADJUSTMENTS L562 module for video installations with twisted pair cable. Locate the CN4 connector, that's placed in the monitor base. Remove the existing jumper and plug the EL562 module. NOTE: on this type of installations the sound module must be setting with SW1-3 to ON (page 115).
  • Page 23: Monitor Connector Description

    MONITOR CONNECTOR DESCRIPTION escription of the RCPL-Plus / RCTK-Plus monitor connector. 50mm. 50mm. Malla Shield Malla Shield Presionar para abrir. Press to open. Colocar la parte superior de la regleta a 1,60m. del suelo. Place the top part of the monitor connector at 1,60m. from the floor. 11758882 CODE LOTE...
  • Page 24: Monitor Installation

    MONITOR INSTALLATION ix the monitor connector to the wall. Avoid to place the monitor near to heating sources, in dusty locations or smoky environments. To install the monitor directly over the wall, drill two holes of Ø6mm. and use the supplied screws. The upper part of the monitor connector must be placed at 1,60m.
  • Page 25: Programming

    MONITORS PROGRAMMING rogramming the Platea Plus / Tekna Plus monitors. Set to ON the switch number 2 of the SW2 configuration dip switch, placed at the upper left side (back) of the module EL631/Plus. The door panel will reproduce a sound to advise that the system has entered into programming mode.
  • Page 26: Description

    TELEPHONE DESCRIPTION escription of the T-940 Plus telephone. Telephone handset. Speaker grille. Microphone hole. Subjection hole. Telephone cord connectors. Function push buttons. On-Off light indicator. Call reception volume control. Hook switch. The telephone has a three positions switch placed on the bottom part of the telephone (closest to the telephone cord connector) that allows to control the call reception level volume.
  • Page 27: Telephone Installation

    TELEPHONE DESCRIPTION erminal connector description. positive, ground. – A , D : audio, digital communication. INT : intercom. SA : auxiliary calling device output. HZ- : door bell push button input. TELEPHONE INSTALLATION ix the telephone. It will be necessary to open the telephone for wiring and fixing purposes.
  • Page 28: Programming

    TELEPHONES PROGRAMMING rogramming the T-940 Plus telephones. Set to ON the switch number 2 of the SW2 configuration dip switch, placed at the upper left side (back) of the sound module. The door panel will reproduce a sound to advise that the system has entered into programming mode.
  • Page 29 TELEPHONE DESCRIPTION escription of the T-740 Plus telephone Telephone handset Speaker grille Microphone hole Subjection hole Telephone cord connectors Door release push button Hook switch Auxiliary function push button Volume control erminal connector description. +, - : Positive, ground. Audio, digital communication. Al : Connection to external door release push button.
  • Page 30: Function Push Buttons

    TELEPHONE DESCRIPTION unction push buttons If the handset is on the craddle sends a panic call to the porter's exchanges that have enabled the reception of this type of call. If not, allows to call to the master porter's exchange. During call reception and communication progresses allows the lock release activation.
  • Page 31: Telephone Installation

    TELEPHONE INSTALLATION ix the telephone to the wall It is necessary to open the telephone for wiring and fixing purposes To open the telephone, insert a plain screwdriver into the slots and gently lever as shown in the drawing Avoid placing the telephone near sources of heat, in dusty locations or smoky environments The telephone can be fixed using an electrical embedding box or directly on the wall, as shown on the picture If the telephone will be...
  • Page 32: Programming

    TELEPHONES PROGRAMMING rogramación de los teléfonos T-740 Plus. Set to ON the switch number 2 of the SW2 configuration dip switch, placed at the upper left side (back) of the sound module. The door panel will reproduce a sound to advise that the system has entered into programming mode. In systems with more than one door panel, the programming process shall be done on the master door panel only.
  • Page 33: Installation Diagrams

    INSTALLATION DIAGRAMS onnexion of an a.c. lock release. If an alternating current lock release has been installed, use a TF-104 transformer and connect it to the lock release as it is shown on the diagram. FA-PLUS/C EL631 PLUS / rev.938072 TF-104 EL640 PLUS ~ ~ ~ ~...
  • Page 34: Video Installation With Coaxial

    INSTALLATION DIAGRAMS Take off JP1 jumper of all the distributors except in the last one. D4L-PLUS Malla Malla D4L-PLUS Malla Malla M =Master. S =Slave. Access door panel Place this power supply as closest as possible to the first distributor. FA-Plus/C o FA-Plus Malla out+...
  • Page 35 ONE OR SEVERAL ACCESSES DOORS ideo installation with coaxial cable. The installation diagram shows the connection of a video system with one or several door panels for the same building. If the system has one access door panel only, override the wiring to the second door panel. If the system has more than one access door panel, wire the second panel as shown on the diagram.
  • Page 36: Video Installation Without Coaxial

    INSTALLATION DIAGRAMS EL562 EL562 * Take off JP1 jumper of all the distributors except in the last one. D6L-Plus/2H EL562 EL562 D6L-Plus/2H M =Master. S =Slave. Access door panel * Place this power supply as closest as possible to the first distributor. FA-Plus/C o FA-Plus Malla out+...
  • Page 37 ONE OR SEVERAL ACCESSES DOORS ideo installation without coaxial cable. The installation diagram shows the connection of a video system with one or several door panels for the same building. If the system has one access door panel only, override the wiring to the second door panel. If the system has more than one access door panel, wire the second panel as shown on the diagram.
  • Page 38 INSTALLATION DIAGRAMS T-940 Plus T-740 Plus T-940 Plus T-740 Plus M =Master. S =Slave. Access door panel *Place this power supply as closest as possible to the first telephone. FA-Plus/C o FA-Plus Malla out+ out- Lock release Main Vd.c.
  • Page 39: Audio Installation

    ONE OR SEVERAL ACCESSES DOORS udio installation. The installation diagram shows the connection of an audio system with one or several door panels for the same building. If the system has one access door panel only, override the wiring to the second door panel. If the system has more than one access door panel, wire the second panel as shown on the diagram.
  • Page 40: Video Installtion (General Panel)

    INSTALLATION DIAGRAMS BACKBONE 1 Inner door panel To monitors EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. D4L-PLUS General door panel BACKBONE 0 M =Master. S =Slave. EL501 mode FA-Plus/C rev.938072 110 0 Malla out+ out- Lock release Main Vd.c.
  • Page 41 GENERAL DOOR PANEL BACKBONE 2 Inner door panel To monitors EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. D4L-PLUS General door panel BACKBONE 0 EL501 mode FA-Plus/C rev.938072 110 0 Malla out+ out- Lock release Main Vd.c.
  • Page 42 INSTALLATION DIAGRAMS BACKBONE 119 Inner door panel To monitors EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. D4L-PLUS ideo installation with general door panel to large residential complexes. IMPORTANT NOTES: To install and configure properly, d o always follow the enclosed information.
  • Page 43 GENERAL DOOR PANEL BACKBONE 120 Inner door panel To monitors EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. ideo installation with general door panel to large residential complexes. SECTIONS CHART Distance Terminal 100m. 300m. +, – , CV1, CV2 1,50mm²...
  • Page 44 INSTALLATION DIAGRAMS To telephones BACKBONE 1 Inner door panel EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. General door panel BACKBONE 0 M =Master. S =Slave. EL501 mode FA-Plus/C rev.938072 110 0 Malla out+ out- Main...
  • Page 45 GENERAL DOOR PANEL To telephones BACKBONE 120 Inner door panel EL500 mode FA-Plus o FA-Plus/C Malla out+ out- Lock release Main Vd.c. udio installation with general door panel to large residential complexes. IMPORTANT NOTES: To install and configure properly, d o always follow the enclosed information.
  • Page 46: Optional Connections

    OPTIONAL CONNECTIONS xternal lock release activation. Placa The lock release can be activated at any moment by using an external push button, that must be connected between 'AP' and ' ' – terminals of the connector Cn5 from door panel (see page 119). Door opening timed at 3 or 15 seconds, with the help of the dip switch SW1-2 (see page 115).
  • Page 47 OPTIONAL CONNECTIONS uxiliary devices activation. To activate auxiliary devices the use of a SAR-12/24 relay unit will be required. If this device is shared for all monitors, link their A1 terminal and use just one relay unit. In case that each monitor has its own application use a SAR-12/24 relay unit for each monitor and don't link the A1 monitor terminals.
  • Page 48 OPTIONAL CONNECTIONS ctivation of a second camera. The use of a SAR-12/24 relay will be required to activate a second camera and an internal modification on the monitor shall be done, as it's described on page 124. This facility disables the intercom function.
  • Page 49 OPTIONAL CONNECTIONS ntercom function. Platea Plus / Tekna Plus monitor and (*) T-740Plus and T-940 Plus telephones have intercom facility between two units of the same apartment . To enable this function check the following conditions: - One of the units has been configurated as master and the other unit as slave with intercom, as described on pages 128, 131 and 135.
  • Page 50: Optional Connections

    OPTIONAL CONNECTIONS uxiliary devices activation with T-740 Plus telephone. First t T-740 Plus telephone must be configured with SW1 dip switch in "PA" output mode function (see page 133). To activate auxiliary devices the use of a SAR-12/24 relay unit will be required. If this device is shared for all the T-740 Plus telephones, link their PA terminal and use just one relay unit.
  • Page 51: Troubleshooting Hints

    TROUBLESHOOTING HINTS An easy way to check that the system is working properly is to disconnect the wiring from the door panel and to check the monitor directly connected to the sound module. No shortcircuit will damage the connected units, with the exception of a shortcircuit between CTO and ' ' –...
  • Page 52: Compliance
