INSTALLATION INSTRUCTIONS FOR PART 89-9400
Discovery / Discovery II 1994-2004
89-9400
KIT FEATURES
DIN Head unit provision
KIT COMPONENTS
A) Trim Plate
A
1-800-221-0932
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
APPLICATIONS
LAND ROVER
TABLE OF CONTENTS:
Dash Disassembly ................ 1
Kit Assembly .......................... 2
Final Assembly ...................... 3
www.metraonline.com
9 E
TOOLS REQUIRED:
86-9001 Radio Removal Tool
Advertisement
Table of Contents
Related Manuals for Metra Electronics 89-9400
Summary of Contents for Metra Electronics 89-9400
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 89-9400 APPLICATIONS LAND ROVER Discovery / Discovery II 1994-2004 89-9400 KIT FEATURES DIN Head unit provision KIT COMPONENTS A) Trim Plate TOOLS REQUIRED: 86-9001 Radio Removal Tool TABLE OF CONTENTS: Dash Disassembly ....1 Kit Assembly ......2 Final Assembly ......
- Page 2 89-9400 LAND ROVER DISCOVERY AND DISCOVERY II Disconnect the negative battery terminal to prevent an accidental short circuit. Insert the long ends of the 86-9001 into the slots on the factory radio and pull out to remove. (Figure A)
- Page 3 89-9400 Snap the 89-9400 trim plate into the bottom of the sub- dash opening. (Figure A) Slide the DIN cage into the space above the 89-9400 and secure by bending the metal locking tabs outward. (Figure B) Slide the aftermarket head unit into the DIN cage until secure.
- Page 4 89-9400 Strip wire ends back 1/2" Twist ends together Solder Tape Locate the factory wiring har- ness in the dash. Metra recom- mends using the proper mating adapter and making the con- nections as shown. (Isolate and individually tape off the ends of...
