Si5341-EVB
1. Functional Block Diagram
Below is a functional block diagram of the Si5341-EVB. This EVB can be connected to a PC via the main USB
connector for programming, control, and monitoring. See section "3. Quick Start" or section "8. Installing
ClockBuilderPro (CBPro) Desktop Software" for more information.
Figure 2. Si5341-EVB Functional Block Diagram
2
Rev. 1.1
