Specifications - Gefen EXT-DP-CP-2FO User Manual

Appendix

Specifications

Supported Formats
Resolution (max.)
Electrical
Video bandwidth
Connectors
Video Input Connector (Sender)
Video Output Connector (Receiver)
Link Connector (Sender / Receiver)
Operational
Power Supply (Sender / Receiver)
Power Consumption (Sender / Receiver)
Optical Power Budget
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Physical
Dimensions (W x H x D)
Unit Weight (each)
• WQUXGA (2560 x 1600 @ 60Hz)
• 10.8 Gb/s (2.7 Gb/s per lane, 4 lanes)
• 1 x DisplayPort 20-pin, female
• 1 x DisplayPort 20-pin, female
• 2 x LC-type
• 5V DC
• 2.1W (max.) each
• 9.4 dB
• +32 to +122 °F (0 to +50 °C)
• -22 to +158 °F (-30 to +70 °C)
• 10 to 85% RH (non-condensing)
• 5 to 90% RH (non-condensing)
• 1.4" x 0.6" x 2.8"
(35mm x 16mm x 72mm)
• 0.1 lb (0.05 kg)
page | 10
