Gefen EXT-DP-CP-2FO User Manual page 15

Getting Started
ID Name
1 Power indicator
2 Power receptacle
3 DisplayPort connector
4 LC connectors
5 Status indicator
Description
This LED indicates the power status of the
Receiver module. See
DisplayPort Extender over 2 LC Fibers
more information.
Connect the included 5V DC power supply
to this power receptacle.
Use a DisplayPort cable to connect the
display to this connector.
Connect two strands of LC-terminated
fiber optic cable from these ports to the
associated ports on the Sender module.
See Connecting the DisplayPort Extender
over 2 LC Fibers
on connecting fiber optic cables.
This LED indicates the connection status of
the Receiver module. See
DisplayPort Extender over 2 LC Fibers
more information on connecting fiber optic
cables.
page | 5
Module Layout
Connecting the
for important information
Connecting the
for
for
