Field Name
Channel
Call Details
Duration
Mode
Voice Coder
IP Call Type
IP Call Direction
Packet Details
Packets Sent
Packets Rcvd
Bytes Sent
Bytes Rcvd
Packets Lost
From – To Details
Gateway Name
(from)
IP Address (from)
Options
Gateway Name (to)
IP Address (to)
Options
DTMF/Other Details
Prefix Matched
Outbound Digits Sent
Outbound Digits
Received
Server Details
DTMF Capability
Table is continued on next page...
Multi-Tech Systems, Inc.
Call Progress Details: Field Definitions
Values Description
1-n This is the channel for which call-progress details are being viewed.
H/M/S The length of the call in hours, minutes, and seconds (hh:mm:ss).
Voice or FAX Indicates whether the call being described was a voice call or a FAX call.
G.723, G.729, The voice coder being used on this call.
G.711, etc.
SIP Indicates the Call Signaling protocol used for the call (SIP).
incoming, Indicates whether the call in question is an incoming call or an outgoing
outgoing call.
integer value Number of voice packets sent over IP network in the course of this call.
integer value Number of voice packets received over IP network during this call.
integer value Number of bytes sent over IP network in the course of this call.
integer value Number of bytes received over IP network in the course of this call.
integer value Number of voice packets lost in the course of this call.
alphanumeric Identifier for the SIP end point gateway that originated the call.
string
n.n.n.n IP address for the SIP end point that originated the call.
SC, FEC Displays VOIP transmission options in use on the current call. These may
include Forward Error Correction or Silence Compression.
alphanumeric Identifier for the VOIP gateway that received the call.
n.n.n.n IP address for the VOIP gateway that received the call.
SC, FEC Displays VOIP transmission options in use on the current call
specified Displays the dialed digits that were matched to a phonebook entry.
dialing digits
0-9, #, * The digits transmitted by the MultiVOIP GSM for this call.
0-9, #, * Of the digits transmitted by the MultiVOIP GSM for this call; these are the
digits that were confirmed as being received.
n.n.n.n The IP address (etc.) of the traffic control server (if any) being used (SIP
and/or other proxy) will be displayed here if the call is handled through that server.
related
descriptions
inband, Indicates whether the DTMF dialing digits are carried "Inband" or "Out of
out of band Band."
Expressions
For SIP it can display either "Out of Band RFC2833" or "Out of Band SIP
differ slightly INFO" to indicate the out-of-band condition or "Inband" to indicate the
for different in-band condition.
Call Signaling
protocols.
MVPGSM
Chapter 6: Using the Software
Description
