System Information screen
This screen presents system information at a glance. It is found under the Configuration section and its primary
use is in troubleshooting. The information presented in the figure below is for reference only and is not meant
to be an exact match of your system.
Field Name
Boot Version
Firmware Version
Configuration
Version
Phone Book Version
Module n
Mac Address
Up Time
Hardware ID
The frequency with which the System Information screen is updated is determined by a setting in the
Logs/Traces screen ("Online Statistics Updation Interval").
Multi-Tech Systems, Inc.
System information screen
System Information Parameter Definitions
Values Description
nn.nn Indicates the version of the boot code that is running on the VOIP. The boot
alpha- code version is independent of the software version.
numeric
nn.nn.nn Indicates the version of the MultiVOIP GSM firmware.
alpha-
numeric
nn.nn. Indicates the version of the MultiVOIP GSM configuration software.
nn.nn
alpha-
numeric
nn.nn Indicates the version of the MultiVOIP GSM phone book being used.
alpha-
numeric
Module This will display the model information of the internal wireless modems.
Info
numeric Denotes the number assigned as the VOIP unit's unique MAC address.
days: Indicates how long the VOIP has been running since its last booting.
hours:
mm:ss
alpha- Indicates version of the MultiVOIP GSM circuit board assembly being used.
numeric
MVPGSM
